Pet Hot Filling Bottle Blow Molding Machine (ZQ-B1500-3)

Product Description

Pet Hot Filling Bottle Blow Molding Machine
ZQ-B1500-3 full-automatic pet stretch blow molding machine is the most stable two-step automatic stretch blow moulding machine. It has three cavities and the maximum capacity of the products is 2.0L. It is special for hot filling bottles, which is made of plastic of crystalline type, such as PET and PP etc.
High pressure clamping system, with horizontal pressure and vertical locking system, will make sure of strong clamping force to prevent mould opening during heating process
Reduce inpulse force the bottom mould with control of right stretching position
Pet Hot Filling Bottle Blow Molding Machine
Blow Moulding Technique
A). Preforms are heated by moving along the preheater and self-rotating. Temperature can be adjusted till it is suitable to blow.
B). Preform is tretched vertically and then horizontally, In the hot cavity. Bottle will be shaped by twice blowing treatment to make PET stay at the crystallzing temperature
Settings
A). PLC colour display: OMRON(Japan)
B). Pneumatic parts: FESTO(Germany)
C). Controller of preform transfer: Servo motor DELTA(TAIWAN)
D). Other electric parts are all world-famous brand
Features
A. Stable performance with advanced PLC.
B. Conveying preforms automatically with conveyor.
C. Strong penetrability and good and swift distribution of the heat by letting the bottles rotate by itself and revolute in the rails simultaneously in the infrared preheater.
D. High adjustability to enable the preheater to preheat preforms in shapes by adjusting the light tube and the length of the reflecting board in the preheating area, and eternal temperature in the preheater with an automatic thermostatic apparatus.
E. High safeties with security automatic-locking apparatus in each mechanical action, which will make the procedures turn into a state of safety in case of a breakdown in certain procedure.
F. No contamination and low noise with the air cylinder to drive the action instead of the oil pump.
G. Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.
H. Strong clamping force with high pressure and double crank links to lock the mold.
I. Two ways of operating: Automatic and manual.
J. Safe, reliable, and unique design of the position of valve to make the air pressure diagram of the machine easier to understand.
K. Low cost, high efficiency, easy operation, easy maintenance, etc, with automatic technological process.
L. Contamination is avoided for the bottle body.
M. Ideal effect of the chilling with the chilling system.
N. Easy installation and starting
O. Low rejection rate: Less than 0.2 percent.
Pet Hot Filling Bottle Blow Molding Machine,equipment information.

TYPE	ITEM	ZQ-B1500-2	ZQ-B1500-3	ZQ-B1500-4	ZQ-B1500-6
CONTAINER	Number of cavity	2 cavities	3 cavities	4 cavities	6 cavities
	Output	2400-2600 pcs/hr	2800-3300 pcs/hr	3800-4200 pcs/hr	5500-6000 pcs/hr
	Max.container volume	2.0L	2.0L	2.0L	2.0L
	Max.neck diameter	38mm	38mm	38mm	38mm
	Max.container diameter	105mm	105mm	105mm	105mm
	Max.container height	300-330mm	300-330mm	300-330mm	300-330mm
ELECTRICAL SYSTEM	Number of lamp	27pcs	36pcs	60pcs	90pcs
	Max.heating power	27kw	36kw	60kw	90kw
	Installation power	38kw	48kw	65kw	96kw
	Actual power consumption	18kw	22kw	40kw	60-70kw
AIR SYSTEM	Operatating pressure	7-9kg/cm²	7-9kg/cm²	7-9kg/cm²	7-9kg/cm²
	Low pressure consuming	1200Ltr/min	1400Ltr/min	2000Ltr/min	3000Ltr/min
	Blowing pressure	25-35kg/cm²	25-35kg/cm²	25-35kg/cm²	25-35kg/cm²
	High pressure consuming	2000-2500 Ltr/min	2000-3000 Ltr/min	3000-3500 Ltr/min	4500-5000 Ltr/min
CHILLER WATER	Operating pressure	5-6 kg/cm²	5-6 kg/cm²	5-6 kg/cm²	5-6 kg/cm²
	Temperatuer	10ºC	10ºC	10ºC	10ºC
	Consuming	5600kcal/hr	7600kcal/hr	19000 kcal/hr	25200 kcal/hr
	Flow rater	30Ltr/min	45Ltr/min	60Ltr/min	200Ltr/min
MACHINE	Machine dimension	3.25x1.5x2.1(m)	4.5x2.1x2.1(m)	4.7x2.1x2.1(m)	7.3x2.2x2.1(m)
	Machine weight	3.1ton	3.9ton	4.1ton	6.35ton

Note: The specifications are subject to change without notice for the further improvement.
Note: Custom production accepted. Any client idea tried.
