Highway Fence Collision Barrier Repair Vehicle for Guardrail Maintenance and Cleaning

Product Description

Product Description
Introducing our cutting-edge Highway Fence Collision Barrier Repair Vehicle, meticulously designed for comprehensive guardrail maintenance and cleaning! This highroad guardrail repair vehicle sets a new standard in efficiency and reliability.
Model number: NJJ5061TQX6
Scope of work: Specifically engineered for the maintenance of corrugated beam steel guardrails on highways, ensuring optimal safety and performance.
Vehicle class: N2
Number of passengers: Accommodates up to five people comfortably.
Maximum travel speed: Capable of reaching speeds up to 100km/h, ensuring quick deployment to maintenance sites.
Fuel: Powered by reliable Diesel oil for robust performance.
Lubricating oil/grease: Utilizes high-quality lithium base lubricating oil for smooth operation.
Hydraulic oil: Equipped with 65# anti-wear hydraulic oil to maintain optimal performance under demanding conditions.
Base plate
Chassis: Built on a durable Jiangling brand Class II chassis, model JX1061TSGA26, featuring air conditioning and directional power for enhanced comfort and control.
Wheel base: 1385mm/1425mm
Wheel base, wheel number, arrangement and specification
Number of rounds: 6
Layout: 4×2 rear axle drive tire specification: 7.00R16LT
Various technical parameters of the engine (type, form, power, fuel consumption)
Engine model: JX4D30B6H Type: High-performance four-cylinder, in-line, water-cooled, electrically controlled high-pressure common rail direct injection, supercharged. Rated power: 85kw, combining power with efficiency.
Driving and braking characteristics
Drive: Hydraulic drive Brake form: Advanced hydraulic double circuit for superior control and safety.
Overall dimensions (L × W × H)
6280mm × 1880mm × 2880mm
Front/rear overhang: 1075mm / 1845mm
Wheelbase: 3360mm
Maximum total weight, quality of service
Working device
Maximum total weight: 6495kg Quality: 4730kg and can carry more than 1 ton of material. This state-of-the-art product boasts its own intellectual property rights, having secured two national patents: ZL201010502209.X, ZL201020558552.1.
The driving mode of the working device: Hydraulic drive, ensuring reliability and precision.
Technical features:
The working device boasts a 270° rotation capacity, providing the flexibility to address the central dividing belt as well as the left and right side guardrails without the need for turning. Equipped with a hydraulic pile pulling mechanism.
Featuring a hydraulic support mechanism at the bottom of the guide rail, this system absorbs all pulling forces, preventing any potential damage to the vehicle's body.
Incorporates a wireless remote control system, allowing for remote operation to mitigate dust-related damage during drilling activities.
Designed with an integrated single-section anti-collision cushion. The rectangular cushion is crafted from light aluminum alloy, with a core filled with aluminum alloy thin film honeycomb material for superior energy absorption.
