Heavy Duty Lifting Stage with Sturdy Hydraulic System for Efficiency

Product Description

Product Description
1,1. Perfectly tailored for scenarios where the lifting platform must be lowered to its minimum height, while still accommodating a substantial stroke and heavy load. Ideal for challenging lifting requirements.
2. Experience a maximum lifting speed of 0.3m/s, ensuring swift and efficient elevation.
3. Enjoy a seamless and smooth rising motion, maintaining a uniform speed for optimal performance.
4. Achieve precise positioning with exceptional synchronization accuracy, enhancing operational precision.
5. Choose between an electronic or hydraulic motor-driven system, both of which are designed to be maintenance-free throughout their lifespan, providing peace of mind and reliability.
6. Benefit from straightforward installation and model selection, coupled with low maintenance costs for cost-effective usage.
7. Ensure safety and sustainability with a design that is pollution-free and generates minimal noise, making it an environmentally friendly choice.
2,The Chain Link Transmission Lift operates on a revolutionary principle: it transforms the horizontally moving chain links within the storage box into vertical movement. These chain links then form robust vertical columns, capable of bearing significant loads, to facilitate effortless vertical lifting.
Detailed Photos
Product Parameters

DYN Load-Pitch of Chain Link
model		07A	11A	15A	19A	23A	27A	31A		35A	39A	47A	53A	63A	71A	77A
trip (m)		DYN Load (kN)
0		6.3	14	25	39	57	78	98		134	173	222	280	360	450	650
0.30		6.3	14	25	39	57	78	98		134	173	222	280	360	450	650
0.50		6.3	14	25	39	57	78	98		134	173	222	280	360	450	650
0.80		6.3	14	25	39	57	78	98		134	173	222	280	360	450	650
1.00		6.3	14	25	39	57	78	98		134	173	222	280	360	450	650
1.20		4.3	12	25	39	57	78	98		134	173	222	280	360	450	650
1.40		3	9	25	39	57	78	98		134	173	222	280	360	450	650
1.60			7	25	39	57	78	98		134	173	222	280	360	450	650
2.00			4	17	39	57	78	98		134	173	222	280	360	450	650
2.50				11	26	57	78	98		134	173	222	280	360	450	650
3.00					18	55	78	98		134	173	222	280	360	450	650
3.50						40	78	98		134	173	222	280	360	450	650
4.00						30	78	98		134	173	222	280	360	450	650
4.50						23	63	98		134	173	222	280	360	450	650
5.00							50	82		134	173	222	280	360	450	650
5.50							40	67		134	173	222	280	360	450	650
6.00							33	55		118	173	222	280	360	450	650
6.50								46		99	159	222	280	360	450	650
7.00								38		84	136	202	280	360	450	650
7.50										72	117	173	280	360	450	650
8.00										62	101	150	280	360	450	650
8.50										53	88	131	258	360	450	650
9.00											76	115	226	360	450	650
9.50												99	200	360	450	650
10.00												80	178	330	450	650
10.50													159	295	450	650
11.00													142	265	450	650
11.50													127	240	450	650
12.00														220	450	620
12.50														195	420	580
13.00														180	390	540
13.50														165	360	500
14.00															330	460
14.50															300	420
15.00															280	380
16.00															260	345
	Please call us for confirmation when selecting model of this color parameters.								The color or above parameters can be selected according to the design.

Certifications
Packaging & Shipping
Company Profile
Project:SHANGHAI EAST CHINA NORMAL UNIVERSITY A comprehensive set-up featuring a double-deck stage steel structure with a robust fence top, complemented by 45 powerful lifting booms, 9 synchronous receivers, a set of versatile movable counters, 4 sophisticated lifting stages, and 2 sets of
lifting orchestras. Included are also a specialized set of lifting railings and a durable steel fire curtain, supported by 45 sets of lifting booms for seamless operations..
Project:Shanghai Wild Animal Park A strategically designed assembly featuring a double-deck stage steel structure with a fortified fence top, integrating 45 high-performance lifting booms, 9 synchronized receivers, a set of agile movable counters, 4 dynamic lifting stages, and 2 sets of lifting orches-
tras. The setup also includes a specialized set of lifting railings, a resilient steel fire curtain, and 45 sets of lifting booms to ensure operational excellence.
Project:Hengdian Film and Television Qinhuai Eight Beauties Theater Featuring a meticulously built stage with a steel structure fence top, this project consists of 46 stage booms, 5 front single-point stages, and a singular steel fire curtain. It is equipped with a lifting orchestra, an orchestra lifting railing, and a plat-
form designed for versatility, including 2 sets of platforms and 2 platform compensation platforms, ensuring diverse performance capabilities.
1. Company Overview
Founded in 2014, Wanying Technology (Taizhou) Co., Ltd. is a vibrant medium-sized industrial manufacturing enterprise situated in the scenic city of Taizhou. Embodying the core values of "customer first, innovation, integrity, optimism, and resilience," we are dedicated to pioneering advancements and creativity in the realms of foreign trade and industrial manufacturing, constantly pushing the boundaries of innovation.
2. Core Business
2.1 Foreign Trade
As a pivotal aspect of our operations, Wanying Technology is laser-focused on broadening and deepening our footprint in the global market. We forge enduring and stable partnerships with numerous renowned companies worldwide, with our products achieving international recognition and acclaim. By relentlessly refining our supply chain management and enhancing service quality, we consistently deliver efficient and superior trade solutions to our clientele.
2.2 Industrial Manufacturing
Within the sphere of industrial manufacturing, Wanying Technology boasts advanced production equipment and a dedicated technical team, passionately committed to the research and production of premium, high-performance industrial products. We stay attuned to industry trends, perpetually innovating our products and technologies to address the ever-evolving and diverse demands of the marketplace.
3. Innovation and Technology
At Wanying Technology, we prioritize technological research and innovation, consistently channeling investments and human resources into the development of groundbreaking technologies and products. We have cultivated close collaborations with a multitude of esteemed universities and research institutions, collectively advancing technological progress and industrial elevation within the industry.
FAQ
1.Is your product customized?
Thanks for your question. Yes, because the working conditions are different, all our products are customized depending on detailed requirement! So if you give us more informaton about the lift capacity, span, lift height, power source and other specials, we will give you a exact quote!
2.What the information should I provide when inquirying?
Thanks for your question. The more information you provide, the accurater solution we can prepare for you! It will be more
appreciated if you give us the information such as the lift capacity, span, lift height, power source or other specials.
3.How many operation methods for my selection?
Thanks for your question. The standard operating methods is controller with push buttons. Meanwhile, we can also provide the group controller.You can choose any of them, just tell us!
4. The space of my workshop is limited, can the crane OK for mine?
Thanks for your question. For low headroom workshop, we have the special products. The detail dimension please consult our professional engineer.
