Model | Drive | Blades Diameter (mm) | Blades Rotational Speed | Motor Rotational Speed | Air Flow (m³/h) | Noise Decibels (db) | Input Power (W) | Voltage (V) | Frequency (HZ) | Outline Size (H*W*T) (mm) |
DJF(d)-1000 | Direct | 1000 | 700rpm | 700rpm | 21000 | ≤64 | 400 | 220 / 380/ Customized | 50 / 60 | 1120*1120*300 |
Round Frame 1. Use thickened galvanized sheet with zinc coating 275g/sqm for no rust. 2.Flanging edge backflow design is adopted for ventilation increasing, vibration and noise reducing, and stability improvement. | |
Hanging Rings Circle hanging rings can be customized to easy installtion. | |
Fan blades Material: mirror stainless steel by punch forming. Advantage: Large air volume, no deformation, no dust, attractive and durable. | |
Motor 1.Sanhe motors with aluminum-magnesium alloy housing good heat emission, high efficiency 2.Reasonable dimension, light weight, low current, big torque. | |
Installation site Experiments have improved that in order to get the best ventilation effect: 1.the optimum installation site is rightly above of the feeding trough. 2. the fan bottom and ground distance is 2.7m 3.Leaning angle controlling within 15° to 30° is the best. | |
Italligent Dynamic-balance Tester Fan blades are adjusted by Intelligent dynamic-balance to ensure the fan smooth running,lower vibration,less noise,increase stability. | |
Installation Diagram |
