Professional Quality Control Team Plastic Pallet Mold Injection Machine for Sale

Product Description

Professional Quality Control Team Plastic Pallet Mold Injection Machine for Sale
Product Description
SINO-TECH ST-2850A injection molding machine is designed for plastic dustbin, chairs, car bump pallet etc. It is with demoulding linkage which shorten the plastic parts cycle time. ST-2850A with high speed, stable performance and it is energy-saving. Our customers can get higher production with same labor and cost.
Main Features
1. 30% higher energy saving than using traditional variable pump.
2. Stable and smooth movement supported by AC servo motor.
3. Effective reduction of energy consumption due to reduced oil.and cooling water attained by hydraulic system.
4. High performance European B&R control system.
Product Parameters

Item		2850JSell
Screw diameter	mm	160	180	200
Theoretical shot volume	cm³	15281	19340	23876
Shot weight (PS)	g	13753	17406	21489
Length/Diameter ratio	L/D	23.0	20.7	18.4
Injection pressure(high pressure and low speed)	MPa	208	165	133
Injection pressure(low pressure and high speed	MPa	164	130	105
Injection rate(high pressure and low speed)	cm³/sec	1262	1597	1972
Injection rate(low pressure and high speed)	cm³/sec	1602	2028	2503
Plasticizing capacity (PS)	g/s	174	230	281
Injection stroke	mm	760
Screw speed	rpm	60
Injection unit force	Ton	31.7
Carriage stroke	mm	1370
Clamping force	Ton	2850
Opening force	Ton	300.3
Opening force	Ton	4100
Max. daylight	mm	2200-3200
Clamping stroke	mm	2000*1800
Distance btwn. Tie bars	mm	1400*1260
Min mould dimension	mm	900-1900
Mould thickness range	mm	70
Ejector force	Ton	53.9
Ejector stroke	mm	450
No. of ejector pins	unit	21
Dry Cycle(Euromap 6)	S	12.5
Major motor	kW	169.8
System pressure	MPa	17.5,20
No. of heater zones	unit	5+1
Heater input power	kW	134
Ultimate capacity	kw	304.8
Current	A	370.5
Net weight	Ton	198
Oil filling capacity	L	2900

Seller Recommendation

Detailed Photos

Application
We are professional plastic injection molding machine manufacturer for all kinds of plastic products, Clamping force from 70 to 1600Ton, injection weight from 50 to 10000g. Also we have CE and ISO certification.

Company Profile

FAQ
1. who are we?We are based in Jiangsu, China, start from 2011,sell to North America(30.00%),South America(20.00%),Western Europe(16.00%),Oceania(10.00%),Mid East(10.00%),Eastern Europe(5.00%),Southeast Asia(5.00%),Africa(4.00%). There are total about 5-10 people in our office.2. how can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.what can you buy from us?Extrusion Blow Molding Machine,Pet Blow Molding Machine,IBC Cage Production Line,Plastic Extrusion Line,Waste Plastic Recycling And Pelletizing Line4. why should you buy from us not from other suppliers?Our company have the strict system from the material purchase,machine part processing and inspect. We have the detailed Assemble prcess according to the machine Assemble structure. We test not one time before the machine delivery to the customer factory.5. what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
