Kaishuo Air Jet Loom Machinery Ksa-718 High Speed Single or Double Nozzle Electronic Feeder Cotton Making Textile/Weaving Machine

Product Description

Product Description
This model is a kind of air-jet loom specially designed for weaving glass fiber. According to the particularity of the fabric, the frame design of this model is reasonable, and it is more suitable for the operator to operate. The warp let-off device can be either electronic let-off or mechanical let-off. The take-up device adopts mechanical type. Crank type four-link beating-up is used and the electronic weft feeder can adopt single spray or double spray. What is more, the innovative air-inflated square-head large cloth roller seat is more convenient for cloth doffing operation.
The maximum coiling diameter can be 600mm (1000 meters). A large coiling mechanism outside the machine can be used also, and the coiling diameter can reach 1000mm (about 2000 meters). The weft insertion system of this model adopts main and auxiliary nozzles and special-shaped reeds. The main and auxiliary nozzles are controlled by solenoid valves, and the lower head scissors are chopping scissors, equipped with a powerful dust-absorbing device.
This machine can weave varnished cloth, laminated cloth, copper clad cloth, etc. The weight of the fabric is 50g/m2-300g/m2. It has the characteristics of low noise, stable operation, energy saving and high cost performance.

Product Parameters

Model No.	KSA-718	Weft Selection	Electronic Single Jet, Jet type
Condition	New	Selvage	Planetary Gear Cutter Edge
Reed Space	135, 150, 190 (cm)	Let-Off	Mechanical or Electronic
Weft Insertion	Main, Auxiliary Nozzle with a Profiled Reed, Single Pump Angle Adjustment, the Electromagnetic Valve Control	Take-Up	Inside or Outside Machine
Power	Through Electromagnetic Brake, Angle Parking	Cutting	Mechanical
Shedding	Crank or Cam	Automatic Stop Device	Weft: 2 Photoelectric Weft Feeler. Warp: 4 or 6 Columns of Electronic Control
Speed	400-600 Revolutions Per Minute	Motor	1.5kw, 1.8kw
Warp Beam	Ф 914mm 800mm or Disk

Company Profile
Established in April 2002, Qingdao Kaishuo Machinery Technology Co., Ltd. is located in Qingdao, a beautiful coastal city, and Wangtai Town, Huangdao District, Qingdao, which is a famous textile machinery town in China. The company has a superior geographical position and convenient transportation by sea, land and air. The company covers an area of 27,000 square meters, with a building area of 14,000 square meters, and has 126 employees, including 43 engineers and technicians. It is one of the rapidly rising and growing industrial enterprises in Qingdao in recent years. After just a few years of development, Qingdao Kaishuo Machinery Technology Co., Ltd. has developed into a professional manufacturer of water-jet looms integrating R&D, manufacturing, sales and service. The company takes "continuous innovation in technology, steady improvement in quality and excellent service" as its business philosophy, strictly follows the enterprise policy of "developing the factory by science and technology, establishing the factory by quality, taking innovation as the soul and putting the brand first", adheres to the management concept of "zero defect in quality" and takes "better quality and better service" as its eternal pursuit. Enterprises attach great importance to the application of "new materials and new processes" in technological development. According to the market demand, we constantly develop new products to meet the requirements of our customers.


Certifications

Exhibition show

Workshop Display

Product Details

FAQ
About Air Jet Loom
Question:What rotate speed can a air jet loom achieve?
Answer:The rotational speed of a loom is related to factors such as reed width, fabric type, and yarn specification. Our KSA-706 model is designed to rotate at a maximum speed of 650 rpm, but it may vary slightly depending on the fabric type.
Question:What is the power consumption of a air jet loom?
Answer:The power consumption of air jet looms is related to the appropriate motor power, typically between 5.5kw,6.5kw and 7.5kw.
