Automatic Pet Water Bottle Blow Moulding Machine (BM-A4)
| US$67,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
BM-A4
Raw Material
PET
Making Method of Parison
Stretch Blow
Automation
Automatic
Computerized
Computerized
Certification
CE
After-sales Service
2 Year
Product Typebody Diameter
20mm-100mm
Moldcavity
4cavities
Transport Package
Wooden Case
Specification
CE
Trademark
Mars
Origin
Zhejiang, China
HS Code
8477309000
Production Capacity
100 Pieces/Year
Product Description
Automatic PET Water Bottle Blow Moulding MachineTechnical parameters:
Model: BM-A4000 Bottle Blow Moulding Machine
Productivity: Depend on bottle design, 3200-4000PCS/H
Product type: Body diameter, 20mm-100mm
Height: 50mm-350mm
Neck diameter:15mm-38mm
Mold Cavity: 4cavities
Mold thick: 240mm
Mold: 500*500mm
Main machine power: Electrical source power 380v 3Phase /220v 3Phase 50/60HZ
Rated Power: 49kw
Really use power:14kw
Air sourceLP air compressor:1.6m3/min 1.0MPa 1set (15KW)
HP air compressor: 1.0m3/min 3.0MPa 2sets (each set 11KW)
Air dryer: 2.0m3/min 3.0MPa 1set
Cooling water Cooling water:15L/min
Size: L*W*H1908*1858*1920mm
Weight: 3600kg
Preform unscrambler: L*W*H2000*950*2480mm
Weight: 250kg
Resin available PET
