PVC Fire Hose Pipe Fabric
| US$0.30-1.00 | 3,000 Meters (MOQ) |
Basic Info.
Hose Coupling Type
Hose Coupling
Fire Hose Length
25m
Working Pressure
1.6MPa
Diameter
1inch-10inch(19mm, 25mm, 40mm, 50mm, 65mm, Ect)
Lining
PVC or Rubber, PU, Copy Rubber
Weaving Type
Plain Weaving
Hose Coupling Structure
Plug-in
Color
as Your Requirements
Size of Fire Hose
1.5 Inch,2 Inch ,2.5 Inch ,3 Inch,4 Inch
Wokring Pressure of Fire Hose
6 Bar -25bar(1.5MPa-7.5MPa
Bursting Pressure of Fire Hose
15 Bar - 75 Bar (1.5MPa-7.5MPa)
Longitude
High Intensity Polyester Filament
Latitude
High Intensity Polyester Fibers or Yarns
Length
10-30m/Roll
MOQ
3000meters
Type
Fire Hose
Certification
Cccf /ISO9001:2008
Transport Package
Packing by PP Bags or Cartons
Specification
65-8-30M
Trademark
Tianxing
Origin
Quanzhou, Fujian, China
HS Code
5909000000
Production Capacity
80000m/Day
Product Description
PVC fire hose pipe fabric
1)The lining of fire hose is PVC, Copy Rubber,TPU .
And the jacket of hose is woven by high intensity of polyester filament or polyester short-fiber( twill/plain ).
2)There are special adhesive ( solid or liquid)between the jacket and the hose.
The canvas hose is soft and highly polished, reduce the flow resistance
3) The fire hose is thinner and softer, lighter and more convenient to use.
4) The fire hose is high pressure resistance, low temperature resistance, anti-corrosion,aging resistance,wear-resisting.
5) We supply different color lining of fire hose :White, blue, black, etc or according to your requirement.
6) We supply different length of firehose : 10m,15m,20m,25m,30m or according to your requirement.
7)The fire hose is packed by poly bag and cartons.
8)The quality of fire hose is guranteed by CE,CCCF, ISO9001:2008
9)The hose use in fire fighting or agriculture or Industry.
| Diameter (Inch/mm) | Working Pressure (MPa/BAR/PSI) | Testing Pressure (MPa/BAR/PSI) | Bursting Pressure (MPa/BAR/PSI) | Length (Meter) |
| 1 25 | 0.8/ 8 /120 1.0/10/150 1.3/13/195 1.6/16/240 2.0/20/300 | 1.2/12/180 1.5/15/220 2.0/20/300 2.4/24/360 3.0/30/450 | 2.4/24/350 3.0/30/450 3.9/39/580 4.8/48/720 6.0/60/900 | 10 15 20 25 30 |
| 1-1/2 40 | ||||
| 2 50 | ||||
| 2-1/2 65 | ||||
| 3 80 | ||||
| 3-1/2 90 | ||||
| 4 100 | ||||
| 4-1/2 115 | ||||
| 5 125 | ||||
| 5-1/2 140 | ||||
| 6 15 |
