Large 20-30mm Solid Acrylic Wood CO2 Laser Cutting Machine 500W 1500*3000mm

Product Description

Large 20-30mm Solid Acrylic Wood Co2 Laser Cutting Machine 500W 1500*3000mm
Features
Laser Head with auto lifting, lifting height with 40mm, for thick materials processing, no need install auto lifting table, more convenient.

Equipped with dual Co2 laser cutting head. A1 head With famous SLW 500W folding Co2 laser tube, for thick material cutting. A2 with Reci W2 90W Co2 laser tube, used for non-metal materials fine engraving & thin cutting.
Driving system
Powerful Panasonic Japan 750W servo motor driver for XY-axis, high precision, fast speed and more stable.
Operation System
Advanced USB port RuiDa RDC6445SDSP control system with wireless handwheel, large inner memory device and Fast curve cutting and Optimized shortest path function, Greatly improved the working efficiency .
With full-process automatic laser power attenuation compensation , ensuring the performance consistency of engraving/cutting. The High speed motion control program with pre-buffering function enhances productivity more.
Completely compatible with various CAD&CAM softwares such as AuotCAD, CorelDAW, supporting the designs directly exporting. With advanced Color management and defining the working turns with different colors , All or a part work can done in one time.
Rationalized placement of the electronic parts. Optimized heat dissipation effect.
Working Table
Knife Strip Table: With oxidation treatment and low reflection ratio Ensured cutting quality
Beam Path System
Adopting imported focus lens with high luminousness and mirror with high relativity ensure stable power transference.
Motion System
Imported High precision, low friction force and stand wear and CSK Taiwan linear guide rails and blocks with with 3M belt ensured stable transmission for X-axis, Y-axis with helical rack pinion transmission, higher running speed and efficiency.
Blow- off system
Air pump(195W) and air blower(550W, 2 sets) for laser head & machine blow-off
Also, with upper smoking device
Cooling System
Large Industrial chiller CW-6000( Teyu S&A brand), ensuring the laser tube long time continus working
With water cooling for lens & mirrors, ensure continusing working
Technical Parameters

Effective working area	1500*3000mm
Laser Type	Co2 sealed-off laser tube
Laser head	Dual, auto lifting laser head
Laser tube power	A1: 500W folding co2 laser tube A2: 90W Glass co2 laser tube
Working table	Knife strip
Driver mode	Panasonic Japan servo motor driver,750W
Guide rail	Linear square guide rail ( CSK,Taiwan)
Transmission	X: 3M belt transmission Y: helical rack pinion transmission
Control panel	English
Laser output control	1-100% software setting
Engraving speed	0-60000mm/min
Cutting speed	0-10000mm/min
Control system	RuiDa RDC6445S with wireless handwheel
Control software	RDWorksV8
Design software when delivery	CorelDraw
Control panel	DSP offline
Resolution accuracy	< 0.01mm
Location precision	< 0.01mm
Highest scanning accuracy	2500DPI
Type of cooling	Industrial chiller CW-6000 cooling(Teyu S&A)
Water protection system	Yes
Blow-off system	Air pump and air blower And, upper smoking
Working temperature	0-45 °C
Operating humidity	5-95% (without condensed water)
Supporting picture format	PLT,DST,DXF,BMP, DWG,AI,LAS,etc
Voltage	AC220V/110V, 50/60Hz, single phase
Certificate	CE/FDA

Applications
Application Industry: Model Field(Construction Model,Aviation navigation model, wooden toys), advertising filed,decorative and decorating, craft gift industry, electronic, garments and leather industry, art glass industry, art glass industry,computerized embroidery and clipping, packaging and paper industry.
Main Cutting Materials: Acrylic, density board(MDF), double-color board, paper, plastic, rubber, cloth, wool, crystal, bamboo products, wooden products, etc
Materials Can work With: Organic glass, acrylic board (the paulownia, lightwood), bamboo products, Double-color board, paper, leather, ceramics, textiles, crystal, jade, coconut shells, horn, resin animal sebum, ABS plate, lamp shade and other non-metallic materials.
Reference Sample Photos
Reference Working Videos
https://youtu.be/3E3dfgaYIX4
Packing
For more information, just feel free to contact us!
