Computerized Metal Bending, Automatic Feeding Material Bending Machine CNC Tube Bending Machine CNC Hydraulic Bending Machine
| US$75,000.00-80,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
DES-2000
Warranty
1-year
Condition
New
Certification
RoHS, ISO 9001:2000, ISO 9001:2008
Automation
Automatic
Suitable for
Copper, Aluminum, Alloy, Carbon Steel, Stainless Steel
Type
Cnc Bending Machine
Bending Length
2000mm
Bending Height
175mm
Bending Thickness
0.35mm
Bending Degree
0-360°
Accuracy of Bending Angle
±1°
Accuracy of Feeding Length
±0.1mm
Clamping Method
Sucked or Pressing
Windows CE
Windows CE
Noise Level
≈40dB
Peak Power
22kw
Weight
18.5 Tons
Transport Package
Pallet, Foam and Plastic Film
Specification
5900* 2900* 3200MM
Trademark
Dontzer
Origin
China
HS Code
8462219000
Production Capacity
300 Sets/Year
Packaging & Delivery
Package Size
1203.00cm * 235.00cm * 239.00cm
Package Gross Weight
18500.000kg
Product Description
Product PhotosProduct Parameters
| DES-2000 | ||
| Fastest bending speed | ≤0.2 sec/knife | |
| Maximum bending length | 2000mm | |
| Bending height | 175mm | |
| rated voltage | 380V | |
| peak power | 22KW | |
| average power | ≈2.2KW | |
| noise value | ≈40db | |
| Overall dimensions | About: L590cm X W290cm X H320cm | |
| total mass | About 18.5 tons | |
| software running platform | Windows CE | |
| software | Dongze self-developed | |
| Clamping method | Custom made | |
| Maximum bending thickness (standard knife) | Stainless steel 1.0mm | Special panels can be customized |
| Cold plate 1.5mm | ||
| Aluminum plate 1.6mm | ||
| Minimum material thickness | 0.35mm | |
| Minimum size for quadrilateral forming | Custom made |
| Minimum size of bilateral one-time forming | About 220mm | Can Be Customized |
| Hinge knives (2 sets) | Apolegamy | |
| Advanced Instructions | √ | Standard Configuration |
| arc command | √ | Standard Configuration |
| Replaceable fixtures | √ | Apolegamy |
| C-axis > 360° | √ | Standard Configuration |
| Self-lubricating systems | √ | Standard Configuration |
| Partial load detection | √ | Standard Configuration |
| Partial load follow-up | √ | Standard Configuration |
| Plate thickness detection | √ | Standard Configuration |
| Automated loading and unloading interface | √ | Standard Configuration |
| Flattening function | √ | Standard Configuration |
| Pressing the dead edge up and down | √ | Standard Configuration |
| handwheels | √ | Standard Configuration |
| Automated Pipeline Interface | √ | Standard Configuration |
| Warranty | 1 year | Lifetime technical support |
Product category
Certifications
Company Profile
FAQ
1. How about the delivery time?
Generally it's 15-30 days based on the model.
2. How is the warranty time?
1 year after installation.
Lifetime free technical support.
3. How to choose the suitable machine?
Please advise us the material/ thickness/ dimension of metal sheet, and the punched drawing.
