Pneumatic Control Element 4V210-08 Two-Position Five-Way Valve 5/2 Port Air Polit Type Directional Control Aluminum Solenoid Valve

Product Description

Pneumatic Control Element 4V210-08 Two-Position Five-Way Valve 5/2 Port Air Polit Type Aluminum Solenoid Valve
Media: Clean Air
Temperature: -5 C~60 C
Pressure: 1.2Mpa
Orifice (mm): 1.2mm
Seal: NBR

Model	4V210-08
Working Medium	Clean Air (40um filteration)
Acting Type	Guid Type
Jiont Size	Import=1/4 Export=1/4 Exhause=1/8
Ways	2 Position 5 Port Single Control
Working Temperature	-5~60C
Oriffice	1.2mm
Woking Pressure	0.15~0.9MPa
Coil Type	Din Type,Flying Leads
Max Acting Frequency	5Time/mm

Solenoid Valve
1.Acting Type:direct acting
2.Coil Type:DIN type/Flyling lead
3.Protective Class:IP65(DIN40050)
4.100% test
4V series directional solenoid valves have 5/2 and 5/3 types, size from M5 to 1/2", while 5/2 types have single solenoid type and double solenoid type, Single solenlid valves is repositioned by the spring, and the double solenoid vavle is repositioned by the coil. 5/3 type solenoid valve can make the cylinder piston stop at any position.
Specificaitons of 4v Series Solenoid Valve (2 Position 5 port single control)

Model	4V110-M5	4V110-06	4V210-06	4V210-08	4V310-08	4V310-10	4V410-15
Working Medium	Clean Air (40 Micrometer Filteration)
Ways	2 Position 5 Port
Acting Type	Direct Acting
Joint Size	Import=M5 Export=M5 Exhaust=M5	Import=1/8 Export=1/8 Exhaust=1/8		Import=1/4 Export=1/4 Exhaust=1/8	Import=1/4 Export=1/4 Exhaust=1/4	Import=3/8 Export=3/8 Exhaust=1/4	Import=1/2 Export=1/2 Exhaust=1/2
Sectional Area	5.5mm2(CV=0.31)	12mm2(CV=0.67)	14mm2(CV=0.78)	16mm2(CV=0.89)	25mm2(CV=1.39)	30mm2(CV=1.67)	50mm2(CV=2.79)
Working Pressure	0.15~0.9Mpa
Guarantee Pressure	1.2Mpa
Working Temperature	-5~60°C
Voltage Range	-15%~10%
Heat Resistant Grade	B
Protective Class	IP65(DIN40050)
Coil Type	DIN Type,Flying Leads
Max Acting Frequency	5 Times/s				4 Times/s

What Is Directional Valve?One of the most fundamental and important components of any fluid power system is the directional-control valve. As the name suggests, directional control valves are used to direct the flow of fluid through the system. Directional control valves control when and where the fluid in the system flows.We will always try to give you smart solution for your automatic systems.
Smart Pneumatic Co., Ltd have a professional team, some of them have working experience in big pneumatic companies, like FESTO China SMC China, China AIRTAC, China EMC and etc, so we are familiar with their products and their supplying chain system.
In the future, Smart Pneumatic will continue follow the core concept "Always Smart Solution" to serives our customers; We will do more products and service innovation, create more value for customers, lift efficiency for their production.
