OEM Corrugated Paper Box Machine Tooth Slotter Rotary Die-Cutting Anvil Cover Rubber Pad

Product Description

OEM Corrugated Paper Box Machine Tooth Slotter Rotary Die-Cutting Anvil Cover Rubber Pad Product Description
Product Introduction
The die-cutting rubber pad is made of polyurethane raw materials with excellentperformance, lmproving the lifespan of rubber pads, Special steel interface design, an beinstalled in both directions, Precision interface without gaps, Replacing the rubber pad only takes15 minutes, Greatly improve production efficiency.
Has a sturdy die-cutting surface,Less prone to scratches duringdie-cutting process,During the high-speed die-cutting process,theoperator only needs to minimize the die-cutting pressure,You can obtainclean die-cutting products, Thereby improving the service life of thedie-cutting machine and rubber pad,Fine sanding treatment on thesurface,While enhancing friction,Ensure smooth operation of the cardboard. Lined with high-quality stainless steel plate,Double sided wiredrawing precision welding and tight fitting roller,The plug-in iron head ismade of mold steel,High strength and not easily deformed,Ensureinstallation flatness,Avoid deformation of the rubber pad during high-speeddie-cutting,Ensure the quality of die-cutting.The surface has been ground,Having a uniform thickness,To ensurethe accuracy of the rubber pad after installation, as well as its adhesion andstability during us,Provide more stable and long-lasting surface die-cuttingquality during operation. With hundreds of different specifications, Adapted to thousands ofbrand printing and die-cutting machines, There is a large amount of stockavailable, Able to meet customer needs in the shortest possible time, Andcan mold and produce according to customer needs, The minimumproduction cycle is 10 days. Direct deal,Significant price advantage,Establish a singleidentification for each rubber pad, More guaranteed quality, High credibility.
Usage suggestions Choose high-quality die-cutting knives,Select the tooth shape of the die-cuttingcutter based on the die-cutting product. Select high-quality waste cleaning sponge,Match the height and thickness of theindentation steel wire according to the die-cutting product. After each replacement with a new rubber pad, The distance between thedie-cutting roller and the rubber cushion roller must be adjusted to the maximumdistance,Gradually increase pressure,Until l can just cut the entire cardboard,The smallerthe pressure, the longer the lifespan of the rubber pad. New rubber pads and replacement molds,There are a few areas that are difficult tocut off,Do not apply excessive pressure,The bottom of the mold blade needs to be raiseduntil it is cut off. High speed operation during die cutting use, Auxiliary die-cutting accessories areprone to wear and tear, requiring timely replacement or supplementation. The die cutting knife on the mold can be replaced according to the actual situationand the requirements of the die cutting product, The number of times the die cuttingplate can be replaced with the die cutting knife cannot exceed two times. The die-cutting knife and spring pad need to be replaced in a timely manner,Timely replacement is required when die-cutting reaches 300000 to 500000 times, Andkeep records every time. Product Parameters

NO.	Die cutting rolier diameter	Rubber cushion width	Thickness of rubber pad	Slot width of die cutting roller interface	Die cutting roller interface groove depth
1	180	125-250	10	25	14
2	200	125-250	9.5	25	14
3	224	125-250	8	25	14
4	250	125-250	10	25	14
5	254	125-250	10	25	14
6	257.7	125-250	10	25	14
7	264	125-250	8.5	25	14
8	268	125-250	10	25	14
9	271	125-218	10	25	14
10	271.5	125-250	10	25	14
11	272	86-260	8-10	25	14
12	278	125-250	10	25	14
13	281	85-250	8-10	25	14
14	283	125-250	10	25	14
15	284	125-250	10	25	14
16	285	125-250	10	25	14
17	288.8	125-250	8.5	25	14
18	290	125-250	10	25	14
19	294.5	125-250	10	25	14
20	302	125-250	10	25	14
21	303	125-250	10	30	14
22	312	125-250	10	25	14
23	321	125-250	10	25	14
24	328.8	125-250	10	25	14
25	332	125-250	9.5	25	14
26	341	125-250	8-10	25	14
27	378	125-250	10	25	14
28	379	250	10	30	14
29	379	125-250	10	25	14
30	381	125-250	10	25	14
31	384	125-250	10	25	14
32	388.9	125-252	8-10	25	14
33	391	125-250	10	25	14
34	394.4	125-250	10	25	14
35	434.2	125-250	10	25	14
36	435	125-250	10	25	14
37	440	125-250	10	25	14
38	464	125-250	10	25	14
39	468	125-250	10	25	14
40	508	125-250	10	25	14
41	516.38	125-250	8-11	25	14
42	591.3	125-250	10	25	14
43	645	125-250	10	25	14
44	701	125-260	8-12	25	14

Detailed Photos
Company Profile
Dongguang Hongyu Machinery Trading Co., Ltd. is located in Dongguang County, Cangzhou City, Hebei Province, a world-renowned packaging machinery base. Since its establishment in 2004, it has been dedicated to providing customers with high-quality cardboard machinery equipment, accessories, and solutions. As a professional machinery trading company, we are committed to becoming a leader in the field of carton machinery trading. Through continuous technological innovation and excellent customer service, we have won wide recognition in the industry and provided a large number of high-quality products for the international packaging industry.
Business Scope:
Sales of mechanical equipment and accessories: We provide a range of industrial machinery and equipment, including but not limited to CNC machine tools, automated production lines, robot systems, etc. Technical Support and Services: Provide comprehensive technical support, including equipment installation, debugging, maintenance, and upgrade services. Customized solutions: Provide customized mechanical solutions based on customer needs to meet specific production requirements. International trade: Our business covers the globe and we have established stable cooperative relationships with suppliers and customers from multiple countries and regions. Core Advantages: Professional team: We have a team of experienced engineers and technicians who can provide professional consulting and technical support. Quality Assurance: We strictly control product quality to ensure that every device meets the highest industry standards. Customer first: Always prioritize customer needs, provide personalized services, and respond quickly. Continuous Innovation: Investing in research and development, constantly introducing new technologies and products to maintain market competitiveness. Company Vision:
Our goal is to become a leading global machinery trading company, creating greater value for our customers through continuous technological innovation and excellent service.
