I9 11th/12th13th Generation RAM 8GB/16GB/32GB Hard Drive 1t/2t Windows10/ Linux OPS PC
| US$280.91 | 1 Piece (MOQ) |
Basic Info.
Model NO.
XYC
Installation
Wall-Mounted
Material
Aluminum
Power Supply Type
AT
Rack Unit
1U
Size Specification
ATX
System Expansion Slot
7 Slots
Resolution
4K 3840*2160
Operating Temperature
0°c~ 45°c
Storage Temperature
-40°c~ 80°c
RAM
4G/8g/16g/32g
SSD
128g/256g /512g/1tb
Transport Package
Paper Packaging
Specification
75 inch
Trademark
MTHGH
Origin
China
Production Capacity
10000 Pieces/Month
Packaging & Delivery
Package Size
282.00cm * 257.00cm * 79.00cm
Package Gross Weight
1.400kg
Product Description
Product Description 2022 Newest OPS Mini PC i9 DDR5 Intel Alder Lake-P CPU 12th Gen Support Four Screen 4K Display Mini PC Fanless Computer Industrial for electronic whiteboard, digital signage, advertising media and all in one control industry. Product Parameters| Processor System | CPU | Intel® Alder Lake-P Platform, 12th Gen Processor, Max. TDP 28W |
| BIOS | AMI UEFI BIOS | |
| Graphics | GPU | Intel® Iris® Xe Graphics |
| Multi displays | 4 Simultaneous 4K Displays | |
| Interface | 1 x HDMI1.4 Out, Resolution 4096 x 2160 @ 30Hz | |
| 1 x Type-C(4K60Hz Display and USB Data) | ||
| 1 x DP1.4 8K30Hz | ||
| 1 x 80PIN JAE Con. HDMI2.0 Resolution 4096 x 2160 @ 60Hz | ||
| Memory | Type | SoDIMM DDR5 |
| Max | 32GB | |
| Ethernet | Lan 1 | 1 x 10/100/1000Mbps |
| Connector | 1 x RJ45 | |
| Wireless | Type | PCIe+USB Wi-Fi/BT Module ,Support Intel CNVi Module |
| Interface | 1 x M.2 2230 For Wifi+BT Module | |
| Storage | Type | SSD |
| Interface | 1 x M.2 Key M 2280 For SATA/NVMe SSD | |
| IO Interface | Front panel | 1 x HDMI1.4 Out |
| 2 x USB3.1 , 2 x USB2.0, 1 x Type-C (4K60Hz Display and USB Data) | ||
| 1 x RJ45 | ||
| 1 x Line-out and Mic-In Two In One Port | ||
| 2 x Wi-Fi/BT ANT | ||
| 1 x Power button, 1 x Reset button | ||
| Rear panel | 1 x JAE 80Pin : 1x HDMI 2.0 2x USB2.0 , 1x USB3.0, TTL | |
| 1 x 2.5/5.5 DC IN JACK | ||
| Software | OS Supports | Compatible Windows10/ Compatible Windows11/Linux |
| Watchdog | Support | |
| vPro/AMT | Support | |
| TPM | Support , TPM2.0(Optional) | |
| Power | Power Input | 12V/19V DC IN, 2.5/5.5 DC Jack & JAE 80pin DC IN |
| Size | Comply With OPS Standard Module,119 x 180 x 30 mm | |
| Environment | Operating Temp. | -10~50ºC |
| Operating Humidity | 10%~90% Non-condensing | |
| Storage Temp. | -20~70ºC | |
| Operating Humidity | 5%~90% Non-condensing |
OPS OPS PC module for Interactive Flat Panel.
Packaging & Shipping
Certifications
FAQ
| Product Name | I9 12th Generation RAM 8GB Hard Drive 128GB Windows10/ Linux OPS PC |
| Q1: | How's the quality? |
| A1: | We are the original factory of the brand "MTHGH",All our products are patented and certified.we have our own R&D team and all our products are manufactured at our own factory with extremely quality control system |
| Q2: | What is the minimum order? |
| A2: | one set only! our company mainly deals with wholesale deals here,but retail and small orders also welcome.we hold retail store at domestic market and oversea such as Amazon,******....Orders here will also enjoy super retail service such as 30 days free return for defective item |
| Q3: | what's the shipment terms and delivery time of your compay? |
| A3: | Well, it's depends on the quantity of your order.We have plenty of stock for standard requirement item normally we can delivery the item 1-2 business day.but if you need OEM/ODM order,the shipment time will last to 7-20 business days |
