GE | Model:IC220PWR201 | |
USA | ||
ac servo motor,electric servo motor |
IC220PWR001 | IC220PWR002 | IC220PWR003 | IC220PWR101 | IC220PWR201 | |
Product Name | Power Terminal 24 VDC | Power Terminal Fused 24 VDC | Power Terminal Fused with Diagnostics 24 VDC | Power Terminal 120 VAC | Power Terminal 230 VAC |
Lifecycle Status | Active | Active | Active | Active | Active |
Input Voltage | 24 VDC | 24 VDC | 24 VDC | 120 VAC | 120 VAC |
Input Voltage Range | 19 .2 - 30 VDC | 19 .2 - 30 VDC | 19 .2 - 30 VDC | 108 -135 VAC | 12 -253 VAC |
Maximum Current | 8 Amps | 8 Amps | 6 .3 Amps | 8 Amps | 8 Amps |
Overload/Short Circuit in Segment Circuit | No | Fuse | Fuse | No | No |
Surge Voltage/Over Voltage | Yes, suppressor diode for voltage limitation | Yes, suppressor diode for voltage limitation | Yes, suppressor diode for voltage limitation | Yes, VAR 275 VAC | Yes, VAR 275 VAC |
Polarity Reversal | Yes, diode connected in parallel as protection against polarity reversal | Yes, diode connected in parallel as protection against polarity reversal | Yes, diode connected in parallel as protection against polarity reversal | N/A | N/A |
Current Consumption from Local Bus UL (mA) | N/A | N/A | 25 mA, maximum | N/A | N/A |
LED Indicators | 24 VDC Voltage Present | 24 VDC Voltage Present and Blown Fuse | Bus Diagnostics and Blown Fuse | 120 VAC supply Present | 230 VAC supply Present |
Required Terminal Strip | (1) IC220TBK087 (Contains 10 strips) | (1) IC220TBK087 (Contains 10 strips) | (1) IC220TBK087 (Contains 10 strips) | (1) IC220TBK204 | (1) IC220TBK204 |
