3000m High Power GPS 2.4G 5.8g Anti-Uav Interference RF Signal Amplifier Module Products

Product Description

Customized 20-6000MHz 100 WattW DDS or VCO Wireless Signal Jammer Module RF Amplifier

Product Information

Basic Specifications
Model: CKJ-RF100
Color: Black
Jammer Module Signal Type: 20MHz to 6GHz
Output Power: 100W each band
Block Radius:20-5000 meters (GPS signal for 5000m)
Power Supply:AC110-240V to DC24-28V
Cooling System:High efficiency aluminum alloy radiator
Working Time:Not-stop Working
Product Size: 200*130*65 mm (without connector)
Product Weight: appr.2.0kg
Package Contents:Jammer Module x 1
Advantage
Output power 50DBm 100W, shielding 20-5000m,Still depends on the strength signal in given area.
Optional each frequency band is separate and with adjustable power from max to off (0), LED indicator lights display VSWR, Over-voltage, Over-current.
100% safe VSWR over protection (isolator) for each modular
Optional designed by DDS technology.Operators are able to regulate the working frequency band and output power of each module through the software. Configuring a specific frequency band can ensure the internal communication in emergency. Product Description
Shenzhen ZHENGJIANGXINTONG(Ching Kong) Technology Co.,Ltd is R&D wireless solutions ODM OEM manufacturer, he is profession at wireless RF technology systems that require extra range, quality, reliability, and stability. Good R&D experience and will be able to meet any of your technical requirements, So we supply RF signal jammer modules OEM/ODM service with wholesale price. the output power are optional and the frequency bands including 20MHz to 6GHz with 10-200Watt, it can jammer for 4G 5G cellular phones, Wi-Fi UHF VHF Signals. Also is defend 100% drones UAVs, like Phantom 4, Phantom 3 Professional, advanced, standard series, inspire series

The modules widely used in Vehicle & Portable jammer model

Application	Signal system	Frequency Range	Model (100W)
Drone Uav	Remote Control/Video transmission/2.4G	2400-2500MHz	RF100-2.4G
	Remote Control/Video transmission/5.8G	5700-5900MHz	RF100-5.8G
	GPS/GLANASS/BEIDOU B1	1550-1620MHz	RF100-1.5G
	GPSL2L5	1170-1280MHz	RF100-1.2G
	Remote Control 868/915	840-940MHz	RF100-900M
	Remote Control 315	310-320MHz	RF100-315M
	Remote Control 433	430-440MHz	RF100-433M
Jamming RCIED Bomb	Radio-Controlled Toys Remote Control	20-100MHz	RF100-50
	Walky-Talky (VHF)	130-180MHz	RF100-150
	Walky-Talky (UHF200)	200-300MHz	RF100-250
	Walky-Talky (UHF300)	300-400MHz	RF100-350
	Walky-Talky (UHF400),CDMA450,Car Alarm	400-500MHz	RF100-450
	Walky-Talky (UHF500)	500-600MHz	RF100-550
	Walky-Talky (UHF600),Cellular 5G600	600-700MHz	RF100-650
Mobile Phone /GPS/WIFI	Cellular 4G700/800	700-800/790-862MHz	RF100-800
	Cellular CDMA850/GSM900	850-900/900-960MHz	RF100-900
	GPS&Satellite L2L5	1170-1280MHz	RF100-1200
	GPS/GLANASS/BEIDOU B1	1550-1620MHz	RF100-1500
	Cellular DCS/PCS	1800-2000MHz	RF100-1800
	Cellular 3G2100/TD2000	2000-2200MHz	RF100-2100
	WIFI&Bluetooth&Wlan&4G2300	2300-2500MHz	RF100-2400
	Cellular 4G2600	2500-2700MHz	RF100-2600
	Cellular 5G 3500/3700	3400-3800MHz	RF100-3600
	Cellular 5G 4800	4800-5000MHz	RF100-4900
	WIFI&Bluetooth&Wlan 5.2G	5000-5500MHz	RF100-5200
	WIFI&Bluetooth&Wlan& 5.8G	5500-6000MHz	RF100-5800
		Signal Source	VCO / White Noise
		Output Power	50db±1 100W
		Working Voltage	DC24-28V
		Working Current	10.0A±0.5
		VSWR	<=1.5
		Dimensions	200*130*64.5 mm (without connector)
		Installation Dimensions	130*70 mm
		Weight	2.0kg
		Connetor	Female -SMA / N Type
		Power Adjust	Adjustable Option
		Pilot Light	LED Pilot Light Of VSWR, Over-voltage, Over-current.
		Operating Temperature	-20ºC ~ 80ºC
		Est. Time	7-10 days

ISO 9001 & 14001 Quality System Certification, All Units Tested Frequency and Output Power Again Before Shippment. 5000 Units The Monthly Production Capacity.

Company Profile Shenzhen Zhengjiangxintong (Ching Kong) Technology Co.,Ltd. established in 2010, we are a professional manufacturer engaged in the research, development, production, sale and service of anti drone system, drone signal jammer, mobile phone signal jammer, jammer signal source module, voltage control oscillator, signal jammer manage system, communication antenna, All products have independent intellectual property rights and certificate.
The products are widely used in such as VIP convoy, prisons, nuclear industry facilities, airports, schools, conference centers, hospitals, museums, churches and more Places that require silence, confidentiality and information security

The company and product passed ISO 9001 & 14001 quality system certification, two standardized production line and 800 square meters workshop office, has a professional research and development team, Several new products are launched every year, Daily production of hundreds of units, each device through the standard data test and ageing test for many times, can guarantee to the development production and delivery of customer orders, The products sell well in more than sixty countries such as the United States, Russia, Poland, Brazil, Britain, Italy, South Africa and other parts of the world.

Welcome customers to visit our factory and have good cooperation!

FAQ
FAQ1. Could I get a sample before bulk order?
Yes, We offer samples for all models, but the sample costs, shipping and taxes paid by the buyer.

FAQ2. What should I do if I don't know about frequency in my country?
Please feel free to contact us with your inquiry, we will find the frequency you need and deal with your problems.

FAQ3. Can I customize frequencies or accept OEM/ODM order?
Yes, we can customize the brand logo and frequencies.
we can customize mobile phone 2G/3G/4G/5G,RF LORA, LOJACK 173MHz, VHF, UHF, Walkie-talkie, 433MHz,315MHz, 868MHz, 915MHz,CDMA450MHz, iDEN, CDMA, GSM, GPRS, DCS, PCS, AWS, WCDMA, UMTS,3G,4G, LTE 700, LTE 800, LTE 2300, LTE 2600, GPS L1, GPS L2, Galileo, Compass, Glonass, WIFI, Bluetooth, WIMAX, UAV, Drone, 5.8G, etc.

FAQ4.Shipment Date
Sample: 1-3 business days, <20 pcs 3-5 days, 20-200 pcs 7-15 days, >200 pcs Negotiate

FAQ5: Delivery Date of the sample by DHL/FedEx/UPS/EMS
USA/Canada/Europe/Asia: 3-5 business days
Middle East/Latin American: 5-7 business days
African: 3-7 business days

FAQ6.Payment Method
T/T, Western Union, PayPal, are available,
*Other methods please contact us with more details.
