Manufacturer 6013 Working Radius 55m Lifting Height 140m Max 6t/Ton 8t/Ton Jib 60m Tip Weight 1.3ton Tower Crane Price for Stationary/Construction/Contruction

Product Description

Product Description
6013 6ton 8ton Jib 60m Tip Weight 1.3ton Tower Crane tower crane enables the entire boom to be disassembled and assembled section by section in the air. Compared with the overall hoisting, the requirements for lifting equipment are greatly reduced, saving disassembly and assembly costs, and it is more suitable for tower crane disassembly and assembly under restricted conditions on the construction site and cross-operation of group towers, effectively controlling product quality.
We have fully automatic robot welding production line for mast sections fabrication made up . The production line is composed with automatic material preparation, welding and maching. All main parts of Dahan tower crane use robot welding, with the most advance carbon dioxide mixed with argon gas shielded welding, it has deep depth of fusion, high quality of welding and stable performance.
The tower crane quality passed several experiments with strict testing.
Dimension of tower crane mast section:
1.5m*1.5m*2.2m for QTZ50 4808/4810/50081.606*1.606*2.5 for QTZ63 TC50121615m*1.615m*2.5m for QTZ60 TC5010/QTZ63 TC50101.68m*1.68m*2.5m for QTZ63 TC50131.8m*1.8m*2.8m for QTZ63 TC5610/QTZ80 TC60101.835m*1.835m*2.5m for QTZ80 TC5513/QTZ100 /TC6010/QTZ125 TC65152.0m*2.0m*3m for QTZ315 TC7040 tower crane
Also we can supply stand section, example L46A3 or L46A1, if you need any information, pls kindly contact with usAdvantages about the flat-top crane
1.reduce the dismounting requirements, lower weight, low mounting height, dismount each mast at a time in the air, save the labor cost, safety and fast.2. it is suitable for crossover work of the cranes, without the tower cap and pull rod, the safety will be increased when there need the crossover work.3. It is suitable for the special requirement about the height, such as airport nearby, tunnel, workshop ,and the construction site with high-tension cable.4. It is suitable for the construction site that has the requirement about the crane boom, it can be used as internal climbing crane in the high-rise buildings, irregular roof or small areas.5. It is very convenient for dismounting in the restricted construction site, dismount each crane boom at a time by manual.6.The steel structure of crane boom has long using life and high safety standard.7. The crane boom is good applicability, high-usage,the design of the topless tower crane boom is easy for realizing the serialization and standardization. Reduce the design and making cost.8. Low design cost, short cycle, can much better satisfy the multiple demands of the customers.
New Series Topless Tower Crane H6015 Construction Machinery Lifting Equipment Ruikai CraneTC6510 tower crane is a kind of horizontal arm support, trolleying, top slewing and jacking climbing tower crane. All the performance parameters and technical index achieve or surpasses the national standard. Its max. work range is 60 meters, free standing height is 50 meters and max. height is 180 meters, rated load moment is 1250kN·m, and max. load moment is 1441kN·m.It's ideal engineering machinery for construction enterprises for its advanced parameters, excellent and reliable performance, beautiful sculpt, polish quality, simple and practical structure, and also its rational price. It has advanced safety settings, can be used safely and maintained conveniently.Parameter flattop QTZ125(TC6510)tower crane
1. Rated lifting moment: 1250kn/m2. Max. Lifting load: 10t3. Working radius: 65m4. Tip load: 1.0t5. Basic height (m): 50m6. Attached height (m): 150m7. The main stressed steel parts of qtz125p flat tower crane use q345b steel, the mast section of tower body is 2m*2m*2.8m, using on -chip- type or standard mast section of two forms of production.8. Light weight, air resistance is small, convenient transportation. Rotary uses double- slewing mechanism, hoisting mechanism uses double speed wound motor drag, run smoothly.
Related tower crane model specifications:

Model	Max load	Jib length	Free standing height	Tip load	Mast section size
QTZ50(4810)	4t	48m	29m	1t	1.5×1.5×2.2m
QTZ50(5008)	4t	50m	29m	0.8t	1.5×1.5×2.2m
QTZ63(5013)	5t	50m	38m	1.3t	1.5×1.5×2.5m
	5t	50m	38m	1.3t	1.6×1.6×2.5m
	5t	50m	42.5m	1.3t	1.6×1.6×2.8m
	6t	50m	40m	1.3t	1.6×1.6×2.5m
	6t	50m	42m	1.3t	1.6×1.6×2.8m
	5t	50m	36.5m	1.3t	1.2×1.2×3.0m
	6t	50m	44m	1.3t	1.2×1.2×3.0m
QTZ80(5610)	6t	56m	42m	1.0t	1.6×1.6×2.8m
	6t	56m	44m	1.0t	1.2×1.2×3.0m
QTZ80(5612)	6t	56m	40m	1.2t	1.6×1.6×2.8m
QTZ80(5613)	6t	56m	42m	1.3t	1.6×1.6×2.8m
	6t	56m	44m	1.3t	1.2×1.2×3.0m
QTZ80(6010)	6t	60m	40m	1.0t	1.6×1.6×2.8m
	6t	60m	45m	1.0t	1.8×1.8×2.8m
	6t	60m	44m	1.0t	1.2×1.2×3.0m
QTZ80(6012)	6t	60m	40m	1.2t	1.6×1.6×2.8m
	6t	60m	45m	1.2t	1.8×1.8×2.8m
	6t	60m	44m	1.2t	1.2×1.2×3.0m
QTZ100(6013)	6t	60m	40m	1.3t	1.6×1.6×2.8m
	8t	60m	45m	1.3t	1.8×1.8×2.8m
	8t	60m	44m	1.3t	1.2×1.2×3.0m
QTZ125(6513)	6t	65m	45m	1.3t	1.8×1.8×2.8m
	8t	65m	45m	1.3t	1.8×1.8×2.8m
QTZ125(6015)	8t	60m	45m	1.5t	2.0×2.0×3.0m
	10t	60m	45m	1.5t	1.8×1.8×2.8m
	10t	60m	44m	1.5t	1.6×1.6×3.0m
	10t	60m	60m	1.5t	2.0×2.0×3.0m
QTZ160(6024)	10t	60m	59.7m	2.4t	2.0×2.0×3.0m
	10t	60m	64.7m	2.4t	2.0×2.0×3.0m
QTZ160(6516)	8t	65m	50m	1.6t	1.6×1.6×3.0m
	8t	65m	50m	1.6t	1.8×1.8×2.8m
QTZ200(6520)	10t	65m	59.7m	2.0t	2.0×2.0×3.0m
	10t	65m	64.7m	2.0t	2.0×2.0×3.0m
	10t	65m	53.5m	2.0t	2.0×2.0×3.0m
QTZ250(7021)	12t	70m	59.7m	2.1t	2.0×2.0×3.0m
QTZ250(7025)	12t	70m	59.7m	2.5t	2.0×2.0×3.0m
QTZ250(7032)	12t	70m	52.5m	3.2t	2.0×2.0×3.0m
	12t	70m	57.5m	3.2t	2.0×2.0×3.0m
	12t	70m	38.8m	3.2t	2.0×2.0×3.0m
QTZ250(7027)	16t	70m	52.5m	2.7t	2.0×2.0×3.0m
	16t	70m	38.8m	2.7t	2.0×2.0×3.0m
QTZ315(7530)	16t	75m	52.5m	3.0t	2.0×2.0×3.0m
QTZ500(8522)	25t	85m	73m	2.2t	2.5×2.5×5.95m

Certifications
Packaging & Shipping
Packaging Details: 40 HC containers; high quality Wodden cage for electrical parts Delivery
Delivery Detail: 25-30 days after received the deposit
Company Profile
Our Advantages
Hoisting mechanism using high-power motor, lifting power stronger, more stable operation; Rotating mechanism block torque is relatively large, relative to other equivalent models, the torque is more powerful. Machine modeling and painting for specialized industrial design, beautiful appearance coordination.
Performance Characteristics:
1. Stronger and better lifting performance.
2. Self-pressure counter weight technology, safe and reliable.
3. Aviation plugs, prevent misconnection; high system reliability and low maintenance cost.
4. Compact design of whole machine, transfer operation is convenient and efficient.
After Sales Service
1. We are very glad that customer give us some suggestion for price and products.2. We supply you installation video to assist you to install the crane to help you save the installation cost3. Send free spare parts within warranty time 4. Provide Installation manual and operation manual ,electric drawing5. 24*7 hours on line service
FAQ
Tower Cranes are available in hammerhead, flat top and luffing jib varieties with different hook heights, jib lengths and capacities.
Unsure which crane to choose? Tell us your requirements and we will assist you in selecting the most appropriate tower crane according to your construction site needs.
Q1: How to confirm a suitable tower crane model?
A1: 1.what is the tower crane height you need?
2.what is the Jib Length?
3.what is the Tip Load?
4.what is the Max.Lifting Load?
5.what is the Power supply?
6.What is the quantity you need? 7.FOB Qingdao price or CIF price, if you need CIF price, please tell me your destination port.
Q2: Can you install the tower crane or hoist for us
A2: Yes, we can send one engineer to your country for installing, but you should bear the cost.
