3040 High Performance Mechanical Radial Drilling Machine High Quality and High Precision

Product Description

Product Description
Rocker Arm Drill Product Introduction
The radial drilling machine, a pinnacle of precision and efficiency in hole processing equipment, is expertly crafted for drilling, reaming, tapping, face trimming, and more. Tailored for both single and mass production, this versatile tool excels with porous large parts and is a staple in general machining workshops. It stands out with the following main features:
Structural Features: Ingeniously designed with a rotating and lifting rocker arm around the column, and a spindle box for horizontal movement on the arm. This exceptional design offers unrivaled convenience, operational flexibility, and a broad range of applications, making it ideal for handling large, heavy workpieces with ease.
Classification: Radial drilling machines are categorized based on their clamping structures into hydraulic and mechanical types. Furthermore, considering varied drilling sizes and mechanical principles, these machines are available in diverse models and specifications, catering precisely to different processing requirements.
Technical Parameters: Key parameters include maximum drilling diameter, the spindle-to-column distance, the spindle end face-to-table distance, and spindle rotational speed. These define the machine's machining prowess and efficiency, ensuring it meets demanding precision standards.
Safety Performance: Equipped with robust safety features like spindle overload protection, spindle travel limit switches, and safety nuts on lifting screws, the radial drilling machine promises secure and faultless operation.
Application: With widespread use across machining departments, the radial drilling machine excels in an array of processes such as drilling, reaming, countersinking, tapping, and boring, making it an irreplaceable asset in machining and production environments.
Operation and Maintenance: Available in manual and CNC modes, with mechanical and hydraulic transmissions, ensuring optimal performance and longevity requires diligent operation and regular maintenance.
In summary, the radial drilling machine is a multifunctional marvel, providing efficient, safe, and reliable hole processing for various metal parts. It is an essential fixture in modern machining workshops, offering unmatched versatility and performance.
Product Parameters
Rocker Arm Drill Product Performance
The radial drilling machine represents a new era of multifunctional excellence, boasting impeccable performance, safety, reliability, ease of use, and maintenance. With hydraulic primary variable speed and quick spindle control, it minimizes auxiliary time. Its hydraulically driven diamond block clamping ensures stability and long-term precision. The quenched guide rails and surfaces maintain accuracy and extend service life. Enhanced with comprehensive safety and external column protection, it ensures operational security.
Classified by clamping structure, radial drilling machines include hydraulic and mechanical types. The hydraulic variant, with its ease of operation and broad application range, is particularly suited for single or mass production of porous large parts and is a vital component in general machining workshops.

Product Name	Radial drill	Radial drill	Radial drill
Product model	3040*13/16	3032	Z3050*13/16
Maximum diameter of hole	casting40/Steel part35mm	casting32/Steel part27mm	casting50/Steel part45mm
Distance from spindle end face to table	430-1210mm	360-1050mm	360-1300mm
Distance from spindle center to column busbar	300-1100mm	260-1050mm	260-1050mm
Spindle travel	220mm	120mm	220mm
Main shaft hole cone	4Mohs	4Mohs	4Mohs
Spindle speed range	34.78.145..75130.560.260.430.920.380.760.1280rpm		34.78.145..75130.560.260.430.920.380.760.1280rpm
Spindle speed class speed	12	6	12
Spindle feed range	0.10-0.25rpm	0.10-0.25rpm	0.10-0.25rpm
Spindle feed series	3	3	3
Swing arm rotation Angle	Plus or minus 180 degrees	Plus or minus 180 degrees	Plus or minus 180 degrees
motor power	2.2kw	1.5kw	4kw
Machine weight	1400kg	9600kg	2400kg
Overall dimension	1500*705*2020mm	1350*705*1880mm	1950*810*2450mm
