Ductile Iron Ggg50 Knife Gate Valve Factory Rubber Seat Manual Operated Water China Slurry Sluice Knife Gate Valve Wafer Lug Knife Gate Valve

Product Description

Ductile Iron GGG50 Knife Gate Valve Factory Rubber Seat Manual Operated Water China Slurry Sluice Knife Gate Valve Wafer Lug Knife Gate Valve
Knife gate valve wafer type PN16 technical specification: Nominal Diameter: DN40-DN2000
Nominal Pressure: 2Bar-10Bar
Design Standard: MSS-SP81
FTF Dimension: MSS-SP81
Flange Connection: ASME B16.5 CL150/DIN 2501 PN10-16/
EN1092 PN10-16 /ISO 7005-2/JIS B2212 10K
Inspection and Test: MSS-SP81/ISO 5208/API598
Knife gate valve wafer type PN16 Material List 1. Body: Ductile Iron GGG25/GGG40
2. Disc: Ductile iron/ Stainless Steel 2Cr13/201//304/316/316L
3. Stem: Stainless Steel 2Cr13/304/316/316L
4. Seat: Rubber
Working temperature
EPDM -45ºC-135ºC
NBR -10ºC-80ºC
5. O-ring:
EPDM -45ºC-135ºC
NBR -10ºC-80ºC

Some Ending Customer:
The main advantages of gate valve include: 1. The fluid resistance of the valve is small. Because the valve body of the gate valve is a straight-through type and the flow of the medium doesn't change direction, the fluid resistance of it is small compared with other kinds of valves.
2. The sealing performance is better than that of other shut-off valves. The opening and closing of it are more convenient.
3. The range of applications is wider. In addition to steam, oil and other media, it can be used in medium containing granular solid and with large viscosity. It can also be used as an air-venting valve and a low vacuum system valve.
4. The gate valve has dual flow directions. It's not subject to the flow directions of the medium. Therefore, it is suitable for use in a pipeline where the medium may change the flow direction. It is also easy to install.
Related products
MOQ
We do not have any MOQ for this valve, 1 set order is also can be accepted.
Delivery It depends on the order quantity, the common delivery time will be 15-20days after received payment.

Small order	Shipment by LCL
Bulk order	Shipment by FCL
Urgent or sample order	By air cargo or courier

Payment way 30% deposit, the balance will be paid before loading.
Hydraulic testing
We promise 100% hydraulic testing before exporting, with the testing machine.
Body testing: 1.5* design pressure
Sealing testing 1.1* design pressure
We can provide a 12-month warranty after the shipping date.
Packing way
Plywood case in exporting standard, bubble plastic packing inside
FAQ:
1. Yes, sample order is available for quality check and market test.

2. Quality is priority, we always attach the importance to quality control from the beginning to the end of the production.Every product will be fully assembled and carefully tested before painting, packing and shipping.
3. It usually takes about 25-30 working days to produce. For big order, it depends on the order quantity.
4. We usually accept T/T, L/C,and others payment.
5. We offer 12months warranty time.
6. Depends on your request, we have standard models in stock. Some special products and big order will be newly produced according to your order.
7. Yes, different models can be mixed up in one container.
8. Our company has been audited and approved ISO9001and WRAS certificate.
9. OEM & ODM services will be provided by us depend on your requirement.
