CH Trough Mix Machinery for Maxing Powder (Paste) Materials

Product Description

CH-10,50,100,150,200,300,400,500,600,1000 Series Groove-Type Mixer
Main application:
This machine is used for mixing the powdery or pastel supplies, making the material of different qualities, its characteristic is that the type of mix is horizontal groove-type thick liquid, mix thick liquid as coherent axle, easy to wash. The parts contacting with the material are all made of stainless steel.

Operating principle:
Use the rotation of the thick liquid leaf in the material groove to mix different qualities material evenly. Round groove mixer material groove and thick liquid leaf turn round backward at the same time, the efficiency of the groove-type mixer than general type and more even it can mix.

Technique parameter:

Model	CH-10	CH-50	CH-100	CH-150	CH-200
Working volume(l)	10	50	100	150	200
Main arm speed(min)	24	24	24	24	24
Mixing cycle/ (min)	5-20	5-20	5-20	5-20	5-20
Main motor(kw)	0.25	1.1	2.2	3	4
Dumping motor(kw)	By hand	0.75	0.75	0.75	0.75
Net weight(kg)	40	280	350	410	520
Overall size(mm)	600 x 280 x 450	980 x 420 x 800	1100 x 440 x 900	1280 x 600 x 1100	1400 x 600 x 1200

Model	CH-300	CH-400	CH-500	CH-600	CH-1000
Trough capacity(kg)	300	400	500	600	1000
Main arm speed(min)	24	24	24	24	24
Mixing cycle/ (min)	5-20	5-20	5-20	5-20	5-20
Main motor(kw)	5.5	5.5	7.5	7.5	11
Dumping motor(kw)	1.1	1.1	1.5	2.2	2.2
Net weight(kg)	520	580	680	750	1200
Overall size(mm)	1850×700×1200	2100×750×1250	110×440×900	1280×600×1100	2280×1100×1500

Company Information: Shanghai Tianjiu Machinery Manufacturing Factory has an independent new product R&D department responsible for developing new products and producing custom-made nonstandard equipment. In order to meet market demands and client requirements, we have developed new types of machines with high pressure suitable for making large tablets and tablets difficult to form,
After Sales Service:
We offer the Preventative Maintenance and After Sales Service. For we strongly feels about the importance of supporting our customers and the product solutions we provide. Consequently we offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year warranty!
Installation Services:
Installation Services are available with all new machine purchases. We will provide the technical know how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.
Customization:
All machine in our factory can be customized depending on your requirements, We have successful experience design machines according to customer's requirement. The machine absorbing advanced technology in the world, is the new generation of the automatic filling and sealing machine. It has the characters like Omron PLC control,
Quality guarantee:
1. Each machine is manufactured by our professional workers.
2. Each machine with a strict inspection before out of storage.
3. Each machine use good quality electric elements.
4. After-sales service commitment: After one month, 3 months...We will have return visiting by phone or mail.
5. The warranty time is one year: Within Warranty period, if under the usage of instruction sheet, any product broken or damage, we will offer the repair service for free or replace for free, but clients pay for the freight from China to local place. If need our engineer go to help, clients need to pay for the freight of round-trip.
6. Beside the warranty days, we continue to provide life-long maintenance services.
Frequently Asked Questions:
Q: Are you a factory or trading company?
A: TJ Machinery is a factory who has rich experiences in food, drinks, medical and cosmetic industrials, we offer OEM services in the last over 10 years, and now we have our own brands and own designed machines for sale!
Q: How long need to ship the machines after order
A: All machines can be ready and shipped in 15 or 30 days after order!
Q: What's the payment you prefer?
A: Our standard payment terms are T/T with 30% deposits and balanced before shipment.
Q: Why should you choose our tablet press and packing machine?
A: We have been specialized in tablet press and packing machine for more then ten years, ND until now have exported mahcines to more than 30 countries
Q: Can you provide after-sale service?
A: Yes, sure. We have engineers available to service overseas.
Q: Can I visit your factory and send team for learning and inspect?
A: Yes, sure. We will do our best to teaching you how to use the machine.
Q: What is our advantages?
A: 1. Competitive price
2. Excellent technical support
3. Best service.
