Kc258A Polyester Yarn Twisting Machine

Product Description

Product Description
KC258A Large Package Two For One Twisting Machine
It is applied to make twisting of single-ply and multiplied industrial yarns like polypropylene yarns, nylon yarns, polyester yarns and aramid yarns etc.
Features
A. The yarn-filled spindle can be selected corresponding to the diameter of the package, so that the large package yarn can be fed into the production process at one time.
B. Equipped with Servo motor driven yarn guide forming, which is easy to adjust the forming length and shape.
C. Manual renegade spindle-braking system is easy to operate, and also good for extending the life of apron belt and spindles.
D. Touch screen display can adjust production parameters as customers' need, making operation simple and convenient.
Product Parameters
KC258A: make twisting of single-ply and multiplied industrial yarns;

Machine structure	Double sides, single layer, thread manually
Twist direction	S or Z
Twist range	35-600T/M (need to be selected)
Rated power	26KW
Spindle drive	Apron belt circulation drive

Spindle gauge: 400mm or 450mm or 550mm or customized;
Traverse: 150mm-250mm (optional according to actual situation)
Winding speed: max. 120m/min ( according to the twist);
Start-up mode: frequency conversion slow start;
Take-up package: max. 5kg or 8kg or 10kg;
Spindle speed range: 1500-5000r/min (according to different yarns);
Spindle tensioner: ball or capsule type;
Winding motor: 1.1KW or 3KW;

After Sales Service
For demo machine set:
10 spindles/set+Machine head;
Wooden case packing;
*provide the spare parts;
*Gurantee: one year;
*Provide remote installation or door-to-door installation service;
*Provide after sales service;
*Welcome to visit our factory;
Certifications
ISO9001; ISO14001; ISO45001; CE;
Company Profile
Zhejiang Kaicheng lntelligent Machinery Co., Ltd. is a national high-tech enterprise dedicated to manufacturing intelligent winders and twisters, and also researching, developing automation control software for high-end textile machinery. Kaicheng insists on technological innovation as its core competitiveness of the enterprise. We focus on researches in the field of twisting and winding technology, and keep up with international level especially some famous brands from Europe. We are the best choice and replacement for European brands. Kaicheng products are being sold not only in China but are exported to Southeast Asia, West Asia and North-America, Central and South America, as well as Europe. Kaicheng has set up full set of advanced processing equipment and technology research centers to take its research activities. Moreover, Kaicheng has established long-term cooperation relations with Donghua University, Wuhan Textile University and other universities; "Modern Textile Machinery Research Institute" and "Postgraduate Training Base" was co-established by Zhejiang Kaicheng Intelligent Machinery Co., Ltd.& Zhejiang Sci-tech University in year of 2020.
