High Quality 2 Heads Spiral Cardboard Paper Paper Core Tube Making Machine
| US$9,800.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
CFJG-50
Paper Core Usage
Industry
Tube Machine Type
Paper Tube Making Machine
Gumming Type
Double Side
Layers of Roll Paper
10 Layers
Reelpipe Speed
1-25m/Min
Wall Thickness of Paper Tube
1 - 5mm
Certification
CE
Condition
New
After-sales Service
Online Solution or Dispatch of Engineer to Solve
Process
Paper Machine
Usage
Packing Paper Machine, Household Paper Machine
Automatic Grade
Automatic
Computerized
Yes
Transport Package
Wooden Case/Pallet
Specification
2700*1600*1800mm
Trademark
Chuangfeng
Origin
Zhejiang, China
HS Code
8441809000
Production Capacity
10 Sets/Month
Product Description
CFJG-50 Common Paper Tube Making Machine| Technical Parameter | Control System | ||
| Paper Layer | 10 Layers | Main motor | 4.0kw Wannan |
| Inner Diameter | 20-100mm | Inverter | 5.5kw Delta |
| Wall Thickness | 1-5mm | PLC | Xinjie |
| Winding Speed | 1-25 meters/min | Operating panel | Xinjie |
| Speed Regulation | by Inverter | Electric Components | CHNT |
| Winding Heads | Two heads single belt | Pneumatic Components | Jingwei |
| Cutting blade | Single high-speed steel blade | Bearing | Haerbin |
| Cutting Way | Pneumatic | ||
| Gluing Way | Double sides | Main Configurations | |
| Online Cutting Length | 1000-5000mm | Paper Reel Stand | 10 Layers Cross Type |
| Working air pressure | 0.6Mpa | Gluing Unit | 10 Layers Spraying Type |
| Power Supply | 380V/3Phase/50Hz | Inner Paper Stand | 1 Set |
| Operator | 1-2 persons | Discharging Shelf | 1 Set |
| Measurement & Weight | Mandrel Shaft | 2 Pieces | |
| Measurement | 2700*1600*1800mm | Belt | 2 Pieces |
| Working Space | 7500*5000mm | Extra Blades | 5 Pieces |
| Weight | 2100kgs | Tool | 1 Set |
Latest Machine
Two heads single belt spial winding
Single blade pneumatic online cutting system (cutting length 1000-5000mm)
10 layers common type paper reel stand * 1 set
10 Layers spraying gluing system * 1set
Common inner paper reel stand * 1 set
Finished tube discharging shelf * 1 set
Finished Paper Tubes
