Fluidized Fluidizing Fluid Bed Boiling Granulator for Pharmaceutical

Product Description

Fluidized Bed Granulator Product Description
The machine is composed of main machine, air handling system, heating system, slurry handling system and control system. When it works, the materials are fed into the silo of the fluid bed granulator, and after the programs and parameters are set according to the process requirements, the machine starts to work. After filtered by the air handling system and heated by the heating system, the air enters the main machine. After going through the slurry handling system, the slurry is sent to the spray gun and sprayed to the materials inside the cavity, and then is bonded with powder to form granules. After the operation is completed according to the set programs and parameters, the silo is pushed out and connected with the lifting material transferring machine for lifting discharging or the vacuum feeder is used to pump the materials to a high position for granule sizing by the granule sizing machine, so as to effectively control dust pollution and cross contamination.
Features
• Through powder granulating, the flow property is improved and the dust is reduced.
• Through powder granulating, its solving property is improved.
• The mixing, granulating and drying processes can be completed in one step inside the machine.
• The operation of equipment is safe, because the anti-static filtering cloth is adopted.
• Operation personnel cannot be damaged if explosion takes place, because there is releasing hole.
• Has no dead corner. Therefore the loading and unloading are quick, light and clean.
• Meets the requirements of GMP.
Applications
Phamaceutical industry: tablet, capsule, low sugar or no sugar granule of chinese medicine.
Foodstuff: cocoa, coffee, milkpowder, juice of granulate, flavoring and so on.
Other industries: peticide, feed chemical fertilizer, pigment, dyestuff and so on.
Pharmaceutical industry: power or granule material.
Coating: Granule, protecting coat of pellet, spare color, slow release film, bowel-dissolve coating, etc.
Product Parameters

Specification			3	5	15	30	45	60	90	120	150	200	300	500
Volume		L	12	22	45	100	155	220	300	420	550	670	1000	1500
Capacity		Kg/batch	3	5	15	30	45	60	90	120	150	200	300	500
Steam	Pressure	Mpa	0.4-0.6
	Consumption	Kg/h	10	18	35	60	99	120	130	140	161	180	310	400
Power of Fan		kw	3	4	4	5.5	7.5	11	15	18.5	22	22	30	45
Power of Electrical Heating		kw	6	9
Noise		db	≤75
Compressed Air	Pressure	Mpa	0.6
	Consumption	M3/min	0.3	0.3	0.6	0.6	0.6	0.9	0.9	0.9	0.9	1.1	1.3	1.5
