Metal Cutting Machinery 2-12mm CNC Automatic Steel Bar Machine

Product Description

Metal Cutting Machinery 2-12 mm CNC Automatic Steel bar Straightening and Cutting Machine
Rebar straightening cutting machine is a kind of auto equipment designed and manufactured by ourselves based on absorbing the advanced electromechanical controlled resistance technology from home and abroad. Combined with a high ratio of performance to price the domestic market launches steel wire straightening and cutting equipment.
Product Parameters

Model	BY-2-12
Cut length	0.7m-12m
Cut error	±1 mm
Speed	0-130m/min
Straightening motor	11+4kw servo
Control mode	Siemens PLC programmable controller
Cut mode	Servo shear
Overall dimension	L 15m*W 1m* H 12m
Weight	3t

Product Feature

Mechanical protection modeling
All high-speed mechanical parts are covered with protective cover to avoid danger to operators.
Main straightener
After high-tech transformation, the main straightener has low operation noise, no more than 40 dB, and the high-speed operation temperature will be stable in a lower range for a long time.
Metal Cutting Machinery 2-12 mm CNC Automatic Steel bar Straightening and Cutting Machine
Product Application Our machinery is widely used in high-speed railway, expressway, bridge tunnel, rail transit, underground pipe gallery, nuclear power, hydro power and other large-scale infrastructure construction and prefabricated buildings, steel processing and distribution center and other fields.
Hylite BY rebar straightening cutting compared with other manufacturers straightener advantages

Equipment Main body	Hylite BY machine	Other manufacturers
Speed	0-130m/min can be automatically adjusted, stepless speed regulation, frequency control	Adopt gear box, shift speed regulation, only 3 fixed speed
Cut-off mode	Servo cutting, high precision, no need for pneumatic clutch	The use of pneumatic clutch control cutting, friction plate wear serious, need to be replaced often, pneumatic components in winter easy to damage, freeze, failure, can not be used normally, cutting error is large
Cut-off box	Adopt crankshaft, bearing shell structure, no wear, cutter position start and stop accurate	Using CAM, top rod structure, serious wear, resulting in cutting tool positioning is not accurate, the steel bar can not be cut
Cutting length	0.02-12m	0.6-12m
Power consumption	Using frequency conversion + servo + numerical control technology, comprehensive power saving 40%	No power-saving technology
Whole machine and accessories life	Domestic unique advanced technology, the whole machine and accessories than other manufacturers increased by 1.5 times	Equipment and accessories wear seriously

Packaging & Shipping

Certifications

Company Profile

All key spare parts of the company are independently produced by us to control their processing accuracy and quality, thereby extending the service life of the machinery.The company has taken the lead in passing the ISO9001:2008 quality system certification and the EU CE product safety certification in the same industry, providing reliable assurance for excellent product quality. The company's machinery and equipment sell well in China, and are exported more than 100 countries and regions such as Romania, Lithuania, Turkey, Poland, Belarus, Ukraine, Russia, Kazakhstan, Saudi Arabia, Egypt, Algeria, South Africa,Vietnam, Thailand, India, Pakistan, Philippines, Indonesia, Australia, Mexico, Colombia, Argentina, Bolivia, Brazil, etc.After more than ten years of development, the company has grown into one of the leading enterprises in the industry. We adhere to the tenet of "customer first, technology leading". In the future, the company will comprehensively promote industrial developmentand upgrading, and build the world's leading steel processing equipment.
