Hyundai Hx405L Crawler Excavator 35tons Stable Performance Promotional Price for Sale
Basic Info.
Model NO.
HX405L
Type
Crawler Excavator
Usage
Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
Bucket
Shovel
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
>1.5m³
Size
Large-Scale
Certification
CE, ISO9001: 2000, EPA
Condition
New
Operating Weight
41300 Kg
Transport Package
Export Package
Specification
11410*3340*3775mm
Trademark
Top brand
Origin
China
HS Code
8429521200
Production Capacity
50000pieces/Year
Packaging & Delivery
Package Size
114.10cm * 334.00cm * 377.50cm
Package Gross Weight
41300.000kg
Product Description
Hyundai HX405L Crawler Excavator 35tons Stable Performance Promotional Price for Sale
Product Description
| SPECIFICATIONS | |
| GENERAL | |
| Operating Weight | 41.3 ton |
| Bucket Capacity | 1.9 m³ (ROCK) |
| ENGINE | |
| Emission | T4 |
| Engine Model | L9 |
| Rated Power | 254 kW/341 hp/346 ps/1900 rpm |
| Max. Torque | 1520 N.M/1100~1400 rpm |
| HYDRAULIC | |
| Main Pumps Rated Flow | 2×333 l/min |
| Implement Circuit (Power Boost) | 350 kgf/cm² |
| PERFORMANCE | |
| Swing Speed | 9.83 rpm |
| Travel Speed | 5.12 km/3.21 hr |
| Max. Gradeability | 35 deg |
| Max. Traction Force | 35.3 ton |
| Bucket Digging Force (ISO) | 24.7 ton |
| Arm Digging Force (ISO) | 19.7 ton |
| TANK CAPACITY | |
| Fuel Tank | 585 ℓ |
| Hydraulic Tank | 210(414) ℓ |
| DIMENSIONS | |
| Overall Length | 11410 mm |
| Overall Height | 3775 mm |
| Overall Width | 3340 mm |
| Tail Swing Radius | 3620 mm |
| Ground Clearance | 570 mm |
| WORKING RANGE | |
| Boom Length | 6500 mm |
| Arm Length | 2800 mm |
| Max. Digging Reach | 10950 mm |
| Max.Digging Depth | 6910 mm |
| Max. Digging Height | 10780 mm |
| Max. Dumping Height | 7650 mm |
| Min. Swing Radius | 4345 mm |
Detailed Photos
