US$9,999.00
|
1 Piece
(MOQ)
|
Basic Info.
Model NO.
KE600-1, KE750-1, KE760-1, KE860-1, KJ125-1
Crushing Style
Grinding & Impact
Compressive Strength (For Crushing)
>300MPA
Crushing Degree
Coarse Crusher
Finished Surface
Hole Process
Spare Parts Supply
for Whole Year
Test&Installation
Engineer Assigned
After-Sale Service
for Whole Using Life
Transport Package
Container, Nude Packs, in Bulk
Specification
ISO9001: 2000
Production Capacity
50-850tph
Product Description
Overview of Small Portable Rock Jaw Crusher
Portable type series Small Portable Rock Jaw Crusher is developed according to novel series stone Crusher Equipment's design idea, which expands the concept field of coarse crushing and fine crushing. Jaw Crusher Series mobile crusher plant is our company's newly developed ore-Crusher Equipment that greatly expends the concept of crushing field. The design of Zenith Small Portable Rock Jaw Crusher gives priority to smoothing out the obstacles of uneven ground, improving producer's efficiency and reducing the cost .
Small Portable Rock Jaw Crusher Working Principle:
The main station and crushing equipment for crushing tyre mobile (optional jaw crusher, impact crusher, cone crusher, impact crusher machine), material feeder uniform delivery to the crusher preliminary broken, was later by the circular vibrating screen form a closed system, realize the circulation of the material crushing, meet size requirements of material from the conveyor output, so as to achieve the purpose of production. The Small Portable Rock Jaw Crusher can be based on actual production the need to remove the circular vibrating screen, and directly to the material preliminary broken, and then with other crushing equipment for specific operation, convenient, flexible.
Small Portable Rock Jaw Crusher Main features
1.Equipped with a large jaw crusher main engine device, boasting a large crushing ratio and a pioneering crushing force.
2.Effective and reliable HJ series high-energy jaw crushers.
3.Compact frame chassis, able to shorten the transportation length.
4.From single application to multiple-in-one application.
5.Global on-site customer service.
6.The preliminary screening function enables the complete set to have a more powerful capacity.
7.Adaptive main engine device switchover can meet customers' personalized needs.
8.Flexible parking function, quick access to the working mode.
Small Portable Rock Jaw Crusher Technical specifications
Model | Specs. of screening equipment | Specs. of crushing equipment | Specs. of main belt conveyor | Hopper volume(m3) | Max.feeding size (mm) | Transportation dimension(mm) |
KE600-1 | TSW0936 | PE600×900 | B800×8.3m | 5.3 | 500 | 12150×2600×3950 |
KE750-1 | TSW1139 | PE750×1060 | B1000×8.5m | 7 | 630 | 13000×2850×4400 |
KE760-1 | TSW1139 | PEW760 | B1000×8.5m | 7 | 640 | 13000×2800×4200 |
KE860-1 | TSW1345 | PEW860 | B1200×9.5m | 8 | 720 | 14600×3000×4500 |
KE1100-1 | TSW1548 | PEW1100 | B1400×9.5m | 11 | 930 | 14050×2900×4000 |
KJ98-1 | TSW1139 | HJ98 | B800×8.3m | 5.9 | 560 | 12150×2600×3950 |
KJ110-1 | TSW1345 | HJ110 | B1000×8.5m | 8.5 | 660 | 13200×3000×4400 |
KJ125-1 | TSW1345 | HJ125 | B1400×9.5m | 8 | 800 | 14600×3000×4500 |
KF1214II-1 | TSW0936 | PFW1214II | B800×8.3m | 5.3 | 500 | 12150×2600×3980 |
KF1315II-1 | TSW1345 | PFW1315II | B1200×9.5m | 8 | 600 | 14600×3100×4500 |
KF1415II-1 | TSW1548 | PFW1415II | B1200×9.5m | 11 | 700 | 14050×3000×4000 |
