Petroleum Asphalt Wne-1A Engler Viscometer with Stainless Steel Materials

Product Description

Product Description
Summary
This instrument is designed and made as per national standard GB/T266 Petroleum Products- Determination of Engler Viscosity, T0622 Bitumen Engler Viscosity Determination(Engler viscometer method) in national industrial standard JTG E20-2011 Standard Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering and Shanghai enterprise standard Q/YXYY11 WNE-1 Engler Viscometer.
I. Main technical features
1. The instrument is composed of tester and temperature controller. Desktop structure.Both of inner and outer crucible adopt stainless materials.Inner crucible has been specially processed.The smooth finish corresponds with the test requirements.
2. The temperature controller adopts digital display type. The parameters set is convenient. The temperature controlling precision is high.
Detailed Photos
Product Parameters

1	Standard water value	(51±1)s
2	Temperature range	(0~100)ºC
3	Temperature control accuracy	±0.2ºC
4	Engler viscosity thermometer	0~50ºC, 0 ºC~100 ºC(for asphalt) 0 ºC~60 ºC, 50ºC~110 ºC(for petroleum)
5	Specification of measuring flas	100/200ml
6	Inner crucible	stainless steel material
7	Power of electric heater	550W(AC220V, 50Hz)
8	Accuracy of electric stopwatch	1/100s(provided by user himself)
9	Dimension	200mm×200mm×400mm(Temperature controller is not included)

Packaging & Shipping
Company Profile
FAQ
Q1: Why Choose NANBEI ?
(1).Professional manufacturer with more than 13 years experience
(2).Exported to more than 97% Countries
(3).Turnkey Solution is no problem
Q2:OEM,ODM acceptable or not?
Absolutely Yes
Q3:What's kind of Payment terms for customer choosing?
T/T ,Western Union, Money Gram , Credit Card, Paypal , L/C ...
Q4:Can you visit your factory online?
Absolutely no problem
Q5:Can online video inspection before shipment?
Absolutely no problem
Q6: what's the MOQ ? Sample order is OK?
MOQ:1 set, sample order is no problem
Q7:What's kind of shipment for customer choosing?
Usually ship by sea, by air, by international express .
We can also provide reasonable solutions according to your transportation requirements
Q8:How to ensure product quality and after-sales service?
We have CE, ISO quality certificate, and SGS authentication.
After-sale service:
Warranty : 1 year We supply free part for quality problem in warranty Long life technical support and service
