M1420 Universal ID Od Grinder

M1420 Universal ID Od Grinder

US$18,200.00 1 Piece (MOQ)

Basic Info.

Model NO.
M1420
Abrasives
Grinding Wheel
Controlling Mode
Artificial
Automatic Grade
Manual
Cylindrical Grinder Type
Universal Cylindrical Grinder
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
ID Grinding Scope
13-100mm
Od Grinding Scope
8-200mm
Max. Loading Weight
50kg
Max. Grinding Length
500mm
Center High
125mm
Max. Rotary Diameter of Work Piece
200mm
Transport Package
Waterproof Film Wrapped, Wooden Case Packaged
Specification
2200x1600x1500mm
Trademark
changyi
Origin
Wuxi, China
HS Code
8460292
Production Capacity
20 Sets Per Year

Product Description


* Universal external grinding machine of M1420B and M1320B
Technical parameter
Main technical parameter
Specification
Model
M1420B
500 750 1000
M1320B
500 750 1000
Central height (mm) 125 125
Center distance (mm) 520,770,1000 520,770,1000
Rotary diameter of maximum work piece (mm) 200 200
Rotary diameter of maximum work piece (mm) 500,750,1000 500,750,1000
External grinding scope (mm) Φ8~Φ200 Φ8~Φ200
Internal grinding scope (mm) Φ13~Φ100 -
Maximum weight of work piece of the center(kg) 50 50
Rotary scope of work table -7°~+7°/ -5.5°~+5.5°/ -3°~+7° -7°~+7°/ -5.5°~+5.5°/ -3°~+7°
External grinding wheel size() Φ400/Φ350×40×Φ127 Φ400/Φ350×40×Φ127
Maximum linear velocity of the grinding wheel(m/s) 35 35
Taper hole of headstock and tailstock (Mohs) 4# or 3# 4# or 3#
Total power of the motor of the machine tool(kw) 5.1 5.1
(kg) 2500,2800,3000 2500,2800,3000
Size of external packing box of the machine tool(L×W×H)(mm) 2200(2700)(3100)×1600×1500 2200(2700)(3100)×1600×1500

Working accuracy

Test property

Test item
regular
MW1420B;MW1320B
Precision level
MM1420B;MM1320B

Grinding accuracy of center work piece
Roundness(mm) 0.0015 0.0012
Cylindricity(mm) 0.005 0.004
Grinding accuracy of short work piece on chuck Roundness(mm) 0.0025 0.002
roughness(μm) Ra≤0.32 Ra≤0.16
Roughness of Roundness(mm) 0.0025(MW1320B) 0.002(MW1320B)
roughness(μm) Ra≤0.63 Ra≤0.32

Table of main accessories Table of special accessories
Name Quantity Name Quantity
Cooling refrigerator 1set Balancing frame of the grinding wheel 1set
Three-jaw chuck 1set Central frame of closed type 1set
Chuck of grinding wheel 1set Central frame of open type 1set
Dresser of grinding wheel 1set Arc dresser 1set
Balancing spindle 1set On-line measuring instrument 1set
Adjusting drill key of the machine tool 3-5set
Loosening nut 1piece
Alloy center 2piece
Inner hexagon socket spanner 1piece
Internal grinding tools 1set(M1420B only M1420B)
