5L Electric Vacuum Mixer with Helical Blade and Water Cold Tank
| US$3,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
CY-6E
Application Area
Metallurgy&Mineral
Certification
CE, TUV
Condition
New
Mixing Drum Shape
Circular Groove
Stirring Type
Spiral
Working
High Speed Mixer
Rate Power
750W
Rotor Rod Speed
0 -1400 Rpm Variable
Lifting
Electric Motor
Container
304ss
Keywords
Electric Vacuum Mixer
Mixer Type
Powder Mixer
Layout Type
Verticle
Operating type
Cycle Operating
Transport Package
Wooden Box
Specification
5L
Trademark
CY
Origin
Zhengzhou, China
HS Code
8438800000
Production Capacity
310 Sets Per Month
Product Description
5L Electric Vacuum Mixer with Single Axis Helical Blade and Water Cold Tankis designed for making large batches (5 liters)
of chemical compounds via blending and mixing in a single container under vacuum driven only by electricity.
It is programmable in speed, time, and rotational direction, and has a stainless steel mixing tank implemented with water cooling to maintain an
efficient mixing process.
This instrument is excellent for preparing LiCoO3, LiFePO4, Phosphor and various ceramic slurries where gas bubbles must be kept at minimum.
The reduction of gas bubbles will result in better dispersion and uniformity of the processed materials.
| Model | Vacuum mixing machine CY-MSK-SFM-6E |
Features | 5 liter 304 stainless steel container with double layer water cooling jacket. Advanced T type sealing to keep vacuum pressure up to 12 hours. Double Step Rotary Vane Vacuum Pump, is included for immediate operation Container is opened or closed by electric motor (no air pump is required any more) Programmable controller to set time, speed, rotation direction. |
| Voltage | 110-240V AC single Phase, 50/60Hz (build-in frequency converter to ensure the mixer can be used under 50 or 60 Hz) |
| Rate Power | 750 W |
| Rotor Rod Speed | 0 -1400 RPM variable |
| Lifting | Electric motor ( no compress are pump required any more ) |
| Water Requirement | 16 L/min water flow required to cool mixing tank Cooling water 1/4'' Inlet and outlet on the back of the mixing tank (with build-in cooling jacket) (water chiller is not included) |
| Vacuum Pump | Double Step Rotary Vane Vacuum Pump, is included Vacuum gauge is built in with minimum vacuum level -0.1 MPa |
| 304SS Container Size | 270mm O.D. x 210mm I.D. x 230mm H |
| Dimensions | 580mm(L) x 320mm(W) x 1340mm(H) |
| Net Weight | 119 kg (262 lbs) |
| Warranty | One year limited warranty with lifetime support |
