High Quality Hyundai 20ton Hx200 Hx200n Crawler Excavator 0.9cbm Bucket Capacity with Kawasaki Pump
Basic Info.
Model NO.
HX200N
Type
Crawler Excavator
Usage
Mining Excavator
Bucket
Grab Shovel
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.5~1.0m³
Size
Medium-Sized
Certification
CE, ISO9001: 2000
Condition
New
Product Name
Hx200 Crawler Excavator
Engine Model
F4.5
Rated Power
125/2200kw/Rpm
Fuel Tank
395L
Hydraulic Oil Tank
160L
Hydraulic System
280L
Boom Length
5680mm
Arm Length
2700mm
Max. Digging Height
9450mm
Max. Dumping Depth
6520mm
Max. Digging Radius
9600mm
Cab Height
3030mm
Carriage Width
2750mm
Rear Turning Radius
2890mm
Minimum Ground Clearance
470mm
Transport Package
Nude
Specification
9525*2800*3030mm
Trademark
HYUNDAI
Origin
China
HS Code
8429521200
Production Capacity
50 Sets/Month
Product Description
Product DescriptionBrand New 20ton HX200N Crawler Excavator with 0.9cbm Bucket Capacity
1. Powerful working ability: The HX200 excavator adopts advanced hydraulic system and high-power engine, has powerful digging and loading capabilities, and can cope with various engineering construction tasks.
2. Efficient operating performance:
The HX200 excavator adopts electronic control system, has precise control and operating performance, and can achieve efficient construction operations.
3. Safe and reliable:
The HX200 excavator has a stable structure and safety protection devices to ensure the safety of operators, and has reliable performance and can work for a long time and high intensity.
4. Energy saving and environmental protection:
The HX200 excavator adopts advanced power system and hydraulic system, has the characteristics of energy saving and environmental protection, can reduce fuel consumption and emissions, and reduce the impact on the environment.
5. Comfortable operation:
The HX200 excavator is equipped with a comfortable cab and high-quality seats, has good noise and vibration control effects, provides a good working environment, and reduces the fatigue of operators.
6. Convenient maintenance:
The HX200 excavator adopts modular design, which makes component replacement and maintenance more convenient, with a short maintenance cycle, which can reduce downtime and maintenance costs.
7. Versatility:
The HX200 excavator can be equipped with a variety of working devices and accessories, such as log grabs, accessory rotators, etc., which can adapt to different construction needs and have high flexibility.
Product Parameters
| Specification | |
| Tonnage (tons) | 20 |
| Machine working weight (kg) | 19900 |
| Bucket capacity (m³) | 0.9 |
| Boom length (mm) | 5680 |
| Arm length (mm) | 2700 |
| Performance | |
| Rotation speed (rpm) | 10.54 |
| Rotation torque(Nm) | 65.3 |
| Walking speed (km/h) | 5.1/3.3 |
| Gradeability(%) | 35 |
| Ground pressure (Kpa) | 0.48 |
| Bucket digging force (kN) | 15.4 |
| Digging force of bucket arm (kN) | 11.6 |
| Maximum traction force(kN) | 22.6 |
| Power system | |
| engine model | F4.5 |
| Rated power (kw/rpm) | 125/2200 |
| Maximum torque(Nm) | 670/1300 |
| Oil capacity | |
| Fuel tank(L) | 395 |
| Hydraulic oil tank (L) | 160 |
| Hydraulic system (L) | 280 |
| Engine oil change amount (L) | 13 |
| Coolant(L ) | 34 |
| Body size | |
| Total length for transport (mm) | 9525 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3010 |
| Cab height (mm) | 3030 |
| Carriage width (mm) | 2750 |
| Total track length (mm) | 4165 |
| Track shoe width (mm) | 600 |
| Track gauge (mm) | 2200 |
| Minimum ground clearance (mm) | 470 |
| Rear turning radius (mm) | 2890 |
Detailed Photos
