OEM S30408 Coil and External Half Pipe Stainless Steel Chemical Storage Tank
| US$58,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
STK-202
Condition
New
Customized
Customized
Certification
ISO9001
Tank Marerial
Metal Tank
Type
Tank Container
Storage Objects
Liquid
Material
S30408
Medium Characteristics
Low Hazardous
Capacity
202,000L
Weight
31,700kg
Oversea Branch
California, USA
ODM
Available
OEM
Available
Specification
202, 000L
Trademark
LUHAO
Origin
China
HS Code
84198990
Product Description
TankMaterial: S30408 Capacity m³: 202 Design pressure MPa: 0.5 Design temperature ºC: 100-120 Work pressure MPa: 0.08 Work temperature ºC: 80-100 Medium: Grease Medium characteristics: Low hazardous
Weight Kg: 31,700
Work life: 10 years
Inner coil
Material: S30408 Capacity m³: 0.42 Design pressure MPa: 0.4 Design temperature ºC: 150 Work pressure MPa: 0.2 Work temperature ºC: 120 Medium: Steam
External half pipe
Material: S30408 Capacity m³: 2.28 Design pressure MPa: 0.4 Design temperature ºC: 150 Work pressure MPa: 0.2 Work temperature ºC: 120 Medium: Steam
*For confidential reason, the drawing is in low definition. If you have any question, please contact us for more information.
https://luhaochemreactors.en.made-in-china.com/product-list-1.html
| LUHAO Chemical Machinery Co. Ltd | |||||
| Pressure Vessel Design Information Collection Table | |||||
| Vessel | Jacket (Coil) | ||||
| Work Medium | Name | ||||
| Components | |||||
| Density (Kg/m³) | |||||
| Characteristics | |||||
| Viscosity (cP) | |||||
| Flow Velocity(m³/h) | |||||
| Design pressure (Mpa) | |||||
| Work pressure (Mpa) | |||||
| Design temperature(ºC) | |||||
| Work temperature (ºC) | |||||
| Wall temperature (ºC) | |||||
| Diamter (mm) | |||||
| Length (mm) | |||||
| Capacity(m³) | |||||
| Effective capacity (m³) | |||||
| Corrosion allowance (mm) | |||||
| Corrosion speed (mm/year) | |||||
| Recommended Materials | |||||
| Lowest value of average monthly temperature(ºC) | |||||
| Site location | |||||
| Installation condition | Indoor or Outdoor | ||||
| Catalyst Volume(m³) | |||||
| Catalyst Density(Kg/m³) | |||||
| Heat Transfer Area(m2) | |||||
| Coil Specification | |||||
| Basic Wind Pressure(Mpa) | |||||
| Seismic Basic Intensity | |||||
| Ambient Temperature(ºC) | |||||
| Site Type | |||||
| Operating Mode | |||||
| Insulation Materials | Name | ||||
| Thickness | |||||
| Density (Kg/m³) | |||||
| Seal Requirements | |||||
| Liquid Level Gauge | |||||
| Emergency Cut-off | |||||
| Static Electricity Removal | |||||
| Anti Eddy Current Requirement for Liquid Outlet | |||||
| Installation and Mantainance Requirements | |||||
| Expected Useful Life (years) | |||||
| Safety accessories | Vessel | Jacket (Coil) | |||
| Location | |||||
| Type | |||||
| Specification | |||||
| Quantity | |||||
| Set pressure(Mpa) | |||||
| Burst disc | |||||
| Burst pressure(Mpa) | |||||
| Safety discharge(kg/h) | |||||
| Agitator | Type | ||||
| Impeller Diameter(mm) | |||||
| Speed(r/min) | |||||
| Motor | Model | ||||
| Power(kw) | |||||
| Explosion Proof Grade | |||||
| Speed reducer | |||||
