Machine Dk7745 with High Quality and Good Price Wire Cutter

Machine Dk7745 with High Quality and Good Price Wire Cutter

US$5,500.00-5,880.00 1 Set (MOQ)

Basic Info.

Model NO.
7745
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Linear Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.005-0.01
Performance Classification
Economical CNC Machine Tools
Certification
GS, CE, ISO 9001
Condition
New
Precision
High Precision
Processing Method
Spark Working EDM Cutting
Type
EDM Wire Cutting
Voltage
Customized, 380V 50Hz
Transport Package
1PC/Wood Packaging
Specification
2050*1800*1700mm
Trademark
Zhenyue / OEM / ODM
Origin
China
HS Code
8456301090
Production Capacity
100sets/Month

Product Description

ZHENYUE New Well Designed CNC Wire Cutting Machine
Main Feature :
-Modular electrical structure and use industry livel IPC, So the system has high stability.
-Design of Sealed type electric cabinet with heat exchange function.
-Fast axis shift shorten the skip machining and taper machining time.
-It applies high precision optical ruler(1 u m)real-time fully closed-loop control, and has absolute coordinate positioning and pitch compensation function.
-Motor and clearance automatic compensation style screw direct-connection reduces the drive clearance
-Fixed cantilever structure give the wire traveling system high stability.
-The enclosed design of machining area.
DK7745 PARANETER Unit
Electrical Specification
Input Voltage V 380
Max.input Power KW <1.5
Max.output Current A 6
Max.material Removal Rate mm³/min 160
Best Surface Finishing um Ra≤0.8
Machinery Specification
Work Table Size mm 650*700
Work Table Stroke mm 500*630
Max.machining Thickness mm 500
Max.workpiece Weight kg 500
Max.cutting Width mm ±3°/150
Wire Electrode Diameter mm 0.12-0.2
Wire Traveling Speed m/s 0.8-11
Machining Accuracy mm ≤0.01
Machine Weight kg 1430
Machine Size(w*d*h) mm 2050*1800*1700
Operating Liquid Water-tank L 100

Zhenyue Group is a specialized company engaging in the Research, Development ,Production and Sales of Mechanical and electrical integrated products.
There are mainly five product series Including: CNC Miller, Machining Center, Plastic Injection Molding Machine, CNC wire cutting Machine, CNC Electrical Impulse.
In recent years Zhenyue has got honours in succession, for example,"One of Top Hundred Key Enterprises in Ningbo", "AAA Credit Company in Ningbo", etc.
Zhengyue products won HI-tech Prize and New Product Prize of the Municipal ,Provincial and State Level. The total construction scale of Zhengyue reaches to 66,000 square meters. With a first-class managing center ,it now has over 500 workers and staffs, among which 30% are R&D personnel. This R&D team allows Zhenyue to develop new products with the worlds most advanced technology.
After-Sale Service :
1. Technical files service provided.
2. On-site training service provided.
3. Free training course at our plant.
4. Lifetime maintenance free of charge.
5. Technical support online service provided.
6. Spare parts replacement and repair service provided.
7. We will provide the consumable parts at an agency price when you need replacement.
FAQ :
How long is the delivery time?
For standard machines, it would be 7-10 days; For non-standard machines and customized machines according to client s specific requirements, it would be 15 to 30 days.
Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
How is the packing?
Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package with Steel Belt
Save space as much as possible for container loading
