Premium Anti-Corrosive Epoxy Vinyl Ester Resin for Pultrusion Profiles, Reinforced Plastic Profiles

Product Description

Product Description Product Name: Epoxy Vinyl Ester Resin HS-4430
1. Brief Introduction: HS-4430 is a premium bisphenol A epoxy vinyl ester resin, meticulously engineered for the fabrication of various types of FRP. This includes anti-corrosive linings, FRP tanks, electrical insulating materials, and FRP molds. HS-4430 is exceptionally well-suited for hand lay-up, pultrusion, and filament winding processes, offering robust mechanical strength, remarkable toughness, and superior heat and corrosion resistance. It stands out as one of the finest resins ever designed for the marine industry. premium resins ever designed for the marine industry.
2. Technical Data Sheet for Liquid Resin:

Item	Standard Requirements	Test Method
Appearance	Yellow Transparent Liquid	GB/T 8237.6.1.1
Viscosity(25ºC,cP)	400-500	GB/T 7193.4.1
Geltime(25ºC,min)	10.0-30.0	GB/T 7193.4.6
Solids Content(%)	60.0-64.0	GB/T 7193.4.3
Acid Value(mgKOH/g)	5.0-13.0	GB/T 2895

Curing system in GT test: Accelerator 0.6Co/Naph: 2%; Hardener AKZO LPT: 2%;
3. Physical properties of casting (for reference only):

Item	Unit	Test Value	Test Method
Tensile Strength	MPa	90	GB/T2568
Tensile Modulus	MPa	3000	GB/T2568
Breaking Elongation	%	6.3	GB/T2568
Flexural Strength	MPa	140	GB/T2570
Flexural Modulus	MPa	3400	GB/T2570
Impact Strength	KJ/m2	19.5	GB/T2571
HDT	ºC	105	GB/T1634
Hardness(Barcol934-1)	--	42	GB/T3854

Note:
1) The casting is made according to GB/T8237-2005; Curing System: Accelerator KC: 1.0%; Hardener AKZO LPT: 1.0%; 2) Post curing: RT×24hrs +80ºC×24hrs;
4. Instruction and attention: 1) To reduce bubbles and achieve a broad gel time scale, use a low-activity curing agent such as Butanox LPT by AKZO. When used as an overcoat layer (e.g., the outermost layer of pipelines and tanks), paraffin must be added to ensure the expected curing degree.
When used as overcoat layer (such an the outermost layer of pipeline and tank), paraffin must be added to ensure the expected curing degree.
2) The recommended paraffin addition is 300ppm (melting point 52~57ºC). To maximize the effectiveness of the paraffin, the resin should have a short gel time (approximately 30 minutes).
3) In order to reduce the bubble and achieve a broad gel time scale, curing agent with low activity such as Butanox LPT produced by AKZO. When used as overcoat layer (such an the outermost layer of pipeline and tank), paraffin must be added to ensure the expected curing degree. The recommended addition is 300ppm (melting point 52~57ºC). At the same time, to employ the paraffin to the best advantage, the resin should have a short gel time (about 30 minutes).
5. Storage:
1) Avoid exposure to heat sources such as direct sunlight or steam pipes. Store in a dry place at temperatures below 25ºC.
2) Keep sealed to prevent moisture absorption and monomer loss. Prolonged storage outside the recommended conditions can affect liquid resin properties like viscosity and gel time.
3) Transportation must comply with the State Council's 'Chemistry Dangerous Articles Safety Management Regulations'. As it contains styrene monomer, it is hazardous and inflammable. Packaging & Shipping Application Certifications FAQ Q: Is Your Company a Manufacturer?
A: Yes, indeed.We have 48,800 square meters factory located in Jiangsu Province, China.
Q: Can I Request a Sample of Unsaturated Polyester Resin?
A: Yes,we can provide 1kg of resin as a free sample, but freight are typically the responsibility of the buyer.
Q: Do you have OEM/ODM service?
A: Yes, we are highly flexible in offering OEM/ODM services.
Q: Can I Customize the Formulation of Unsaturated Polyester Resin for My Project?
A: Yes, absolutely. We understand that different projects may have unique requirements. Our R & D department is well-equipped to handle custom formulations based on your specific needs. You can provide us with the details of your project, including any specific characteristics or performance criteria you are looking for, and our experts will work on tailoring a formulation that meets your requirements.
Q: How Do I Choose the Right Unsaturated Polyester Resin for My Application?
A: We would provide guidance on selecting the appropriate UPR based on different project requirements.
Q: What Certifications and Quality Standards Does Your Unsaturated Polyester Resin Meet?
A: Our Unsaturated Polyester Resin meets CCS, RoHS, REACH, EMS, and QMS certifications and quality standards.
Q: What is Your Company's International Transportation Form?
A: For samples, we offer Delivery Duty Paid (DDP) services for most of the countries. This means that we handle the delivery process, including the payment of taxes, and you won't be required to manage customs clearance. For bulk orders, we normally transported by sea or land. Our commitment is to ensure the secure and efficient delivery of our products to your specified destination.
Q: What is The Product Lead Time?
A: 15 days.
Q:Can I Get a Lower Price for a Large Quantity Order ?
A: Absolutely. The online price serves as a reference, but due to fluctuations in raw material costs, our sales team can provide you with the most accurate and competitive pricing. Before making a purchase, kindly engage with our sales representatives. They will work closely with you, taking into account your order quantity and specific requirements, to ensure you receive the best and most cost-effective pricing tailored to your needs.
Q:What's Shelf Life of Unsaturated Polyester Resin ?
A: Normally 6 months.
