Hydraulic Cheap Price iPhone Phone Case CE Certification Plastic Injection Machine

Hydraulic Cheap Price iPhone Phone Case CE Certification Plastic Injection Machine

US$31,200.00
1-2 Pieces
US$21,200.00
3+ Pieces

Basic Info.

Model NO.
ST-260SElll
Type
Preform Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic
Automation
Automatic
Computerized
Computerized
Certification
CE
Transport Package
Woolen Case
Trademark
SINOTECH
Origin
Made in China
HS Code
8477101090
Production Capacity
1000/Year

Product Description

260 Ton Hydraulic CHEAP PRICE iphone phone case CE certification plastic injection machine
Product Description
SINO-TECH ST-260SEIII injection molding machine is designed for plastic dustbin, chairs, car bump pallet etc. It is with demoulding linkage which shorten the plastic parts cycle time. ST-260SEIII with high speed, stable performance and it is energy-saving. Our customers can get higher production with same labor and cost.
Main Features
1. 30% higher energy saving than using traditional variable pump.
2. Stable and smooth movement supported by AC servo motor.
3.Effective reduction of energy consumption due to reduced oil.and cooling water attained by hydraulic system.
4. High performance European B&R control system.
We are professional plastic injection molding machine manufacturer for all kinds of plastic products, Clamping force from 70 to 1600Ton, injection weight from 50 to 10000g. Also we have CE and ISO certification.
Product Parameters
Item 260SElll
Screw diameter mm 55 60 70
Theoretical shot volume cc 713 848 1155
Shot weight (PS) g 649 772 1051
Shot weight (PS) oz 22.9 27.3 37.1
Length/Diameter ratio L/D 22.9 21 18
Injection pressure MPa 211 178 131
Injection rate cm³/sec 237 282 384
Injection stroke mm 300
Max. Screw speed rpm 175
Plasticizing capacity (PS) g/s 32.3 35.2 52.9
Injection unit force Ton 9.1
Carriage stroke mm 350
Clamping force Ton 260
Max. daylight mm 1210
Clamping stroke mm 600
Distance btwn. Tie bars mm 580*580
Min mould dimension mm 400*400
Mould thickness range mm 195-610
Ejector force Ton 11.1
Ejector stroke mm 180
No. of ejector pins unit 13
Max. motor power kW 26.7
System pressure MPa 17.5
Hydraulic pump capacity L/min 172
No. of heater zones unit 5+1
Heater input power kW 18.9
Ultimate capacity kw 46.6
Current A 63.7
Net weight Ton 8.55
Oil filling capacity L 480

Detailed Photos
Company Profile

FAQ
1. who are we?We are based in Jiangsu, China, start from 2011,sell to North America(30.00%),South America(20.00%),Western Europe(16.00%),Oceania(10.00%),Mid East(10.00%),Eastern Europe(5.00%),Southeast Asia(5.00%),Africa(4.00%). There are total about 5-10 people in our office.2. how can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.what can you buy from us?Extrusion Blow Molding Machine,Pet Blow Molding Machine,IBC Cage Production Line,Plastic Extrusion Line,Waste Plastic Recycling And Pelletizing Line4. why should you buy from us not from other suppliers?Our company have the strict system from the material purchase,machine part processing and inspect. We have the detailed Assemble prcess according to the machine Assemble structure. We test not one time before the machine delivery to the customer factory.5. what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW,Express Delivery;Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
