Lty2000pet Preform Injection Molding Machine for Pet Bottle
| US$32,000.00 | 1 SET (MOQ) |
Basic Info.
Model NO.
LTY-PET-2000
Type
Plastic Product Injection
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008, GMP, QS
Transport Package
Wrap Film Packing Into The Container
Specification
200T
Trademark
LOYALTY
Origin
China
HS Code
8477101090
Production Capacity
1000sets/Years
Product Description
| SPECIFICATION | LTY2000 PET | |||||||
| B | ||||||||
| INJECTION UNIT | ||||||||
| SCREW DIAMETER | mm | 70 | ||||||
| SCREW L/D RATIO | L/D | 25 | ||||||
| SHOT VOLUME(THEORETICAL) | cm3 | 1134 | ||||||
| INJECTION WEIGHT(PS) | g | 1224 | ||||||
| INJECTION RATE | g/s | 400 | ||||||
| INJECTION PRESSURE | MPa | 130 | ||||||
| SCREW SPEED | rpm | 126 | ||||||
| CLAMPING UNIT | ||||||||
| CLAMP FORCE | KN | 2000 | ||||||
| OPEN STROKE | mm | 475 | ||||||
| SPACE BETWEEN TIE BARS(W*H) | mm | 530x530 | ||||||
| MAX.MOULD HEIGHT | mm | 560 | ||||||
| MIN.MOULD HEIGHT | mm | 200 | ||||||
| EJECTOR STROKE | mm | 140 | ||||||
| EJECTOR FORCE | KN | 90 | ||||||
| OTHER | ||||||||
| MAX.PUMP PRESSURE | MPa | 16 | ||||||
| PUMP MOTOR POWER | kW | 18.537 | ||||||
| HEATING POWER | kW | 22.7 | ||||||
| MACHINE DIMENSION(L*W*H) | m | 6.5*1.8**2.3 | ||||||
| OILTANK CUBAGE | L | 300 | ||||||
| MACHINE WEIGHT | t | 7.2 | ||||||
