ATV Power Winch Electric off-Road Winch

Product Description

XQME-2500W ATV Winch with CE Approval
Main technical parameters:
Rated line pulling: 2500lbs (1134kgs) Single-line
Gear Ratio: 153: 1
Gear train: NGWN type planetary gear transmission
Clutch: Turn
Motor: Permanent magnet DC 12V motor with 0.9HP output
Battery Leads: 6/25" ² × 6.23'(6mm² × 1900mm)
Control:
1/50" ² × 10.17'(0.5mm² × 3100mm) Black
1/50" ² × 10.17'(0.5mm² × 3100mm) Green
1/50" ² × 4.26'(0.5mm² × 1300mm) Red
Motor Leads: 6/25" ² × 4.26'(6mm² × 1300mm)
Overall Dimension: (LxWxH) 11.85" × 7.40" × 4.72" (301× 188× 120mm)
Drum size: Φ 1.61" (D)× 2.9" (L) Φ 41(D)× 74(L)mm
Fairlead: Included
Cable length: 50ft(L) ofΦ 3/16" 15.2m(L) ofΦ 4.5mm
Mounting Pattern: 3.67" 93mm
Packing
Packing size: 51.5× 38× 18.5cm
Qty. /CTN.: 2PCS
G. W. /N. W.: 22/20kg
Electric winch is vehicle and vessel rescue equipment and multi-functional towing equipment. It is mainly used in special-purposed vehicles such as cross-country vehicles, all-terrain vehicle, motor homes, carrier vehicle, firefighting vehicles, rescue vehicles, road wreckers and pleasure boats and ships. The winch can be used for self rescue and towing and assisting others in the snow, swamp, desert, beach, rocky and muddy mountain road or towing, pulling goods, hoisting in other conditions. It is a necessary safety device for army, police, oil industry, hydrology, environmental protection, forestry, traffic, public security, frontier defense, logistic and outdoor activities.
