Heavy-Duty Disc Plow for Versatile Agricultural Soil Tillage

Product Description

Product Introduction:
A disc plow is an agricultural tillage machinery mainly used for soil plowing operations. The following are the main features and functions of a disc plow:
1.Working principle:
The disc plow is pulled or suspended by a tractor, and uses the concave disc on it to plow the soil. When the disc plow is pulled forward by the tractor, the disc rotates around its central axis, and the soil around the disc is cut open. The plowed soil rises along the concave surface of the rotating disc and flips back to the side, leaving a plow groove after plowing.
2.Structural composition:
A disc plow is usually composed of a plow frame, a disc shaft, and disc blades. Some disc plows also include components such as left arm shell, left support arm, gearbox, transmission gear, meshing sleeve, control lever, sprocket box, etc. The disc is the main working component of the disc plow, which can perform movements such as lifting, tilting, rotating, and extending to achieve flexible and accurate operation
3.Type:
There are various types of disc plows, including two large types: ordinary and vertical. Both the ordinary disc plow and the vertical disc plow have a 10 ° to 30 ° deviation angle between the disc rotation plane and the forward direction, which plays a role in pushing the soil and enhancing the disc's ability to penetrate the soil. The rotating surface of the vertical disc plow is perpendicular to the ground surface, with only a deviation angle and no inclination angle. It is mainly used for shallow plowing and stubble cutting.
Product parameters:

Disk plow

Model

1LY220

1LY320

1LY420

1LY520

1LY225

1LY325

1LY425

1LY525

1LY625

1LY230

1LY330

1LY430

1LY530

Work width

40cm

60cm

80cm

100cm

50cm

75cm

100cm

125cm

150cm

60cm

85cm

110cm

135cm

Depth

15cm

20cm

25cm

30cm

Auxiliary power

15-24hp

25-40hp

35-50hp

45-65hp

40-50hp

50-80hp

75-105hp

90-120hp

100-150hp

40-50hp

50-80hp

75-105hp

90-120hp

Ploughshare diameter

510mm

600mm

660mm

Product Tupian:
This is the basic structure and parameters of a disc plow
Product application direction:
The disc plow is suitable for various types of soil, including clay, loam, sandy soil, etc. In areas with hard soil or rocks, the design of a disc plow needs to be more sturdy and durable.
Packaging and transportation:
Company Profile:
Shandong Bodilan Machinery Co., Ltd. stands at the forefront of the agricultural machinery industry, renowned as a modern, comprehensive entity dedicated to research, development, production, and sales of top-tier agricultural machinery. As one of the industry's giants, it specializes in farming, harvesting, and management solutions that elevate agricultural productivity.
Our diverse product line encompasses highly adaptable agricultural machinery compatible with tractors ranging from 12-300 horsepower. Our offerings include plows, rotary tillers, disc plows, disc harrows, and deep loosening machines; precision sowing machines for crops such as wheat, corn, and soybeans; specialized planting and harvesting machines for potatoes and sweet potatoes; as well as a variety of grass machinery like lawn mowers, rakers, and balers. Additionally, we provide fertilizer spreaders for granular and organic fertilizers, sprayers, cultivators, ridgers, excavators, agricultural trailers, and a comprehensive array of machinery accessories. We also cater to bespoke requests, crafting products based on customer designs and specifications. With a robust sales network extending across numerous provinces and international markets, our products are esteemed for their reliability and have garnered widespread acclaim globally.
Boasting state-of-the-art processing equipment, including laser cutting machines, CNC machining centers, and advanced product welding and assembly lines, Bodilan Machinery significantly enhances its equipment quality and R&D capabilities. Committed to delivering modern agricultural machinery with exceptional service, we maintain a diverse procurement strategy for key components in global markets, ensuring consistent product quality. Our extensive network of nearly one hundred long-term supplier partners spans 25 provinces, cities, and autonomous regions within China.
Driven by the market and user needs, we tirelessly advance the integration of agricultural machinery and agronomy, fueling product innovation and development. Our strategic vision centers on 'survival through quality, development through quality, and efficiency through quality.' Guided by the principles of 'honesty and trustworthiness, customer first, quality first,' we prioritize independent innovation to forge core competitive advantages, bolstering our market presence within the agricultural machinery and equipment industry.
Shandong Platinum Dylan Machinery Co., Ltd. stands as a beacon of excellence, relying on a robust quality management system, cutting-edge production processes, and unwavering product reliability. Our stellar after-sales support ensures customers receive only the finest products. We warmly welcome global friends to inquire, negotiate, and inspect. Let's collaborate for mutual success and shared brilliance!
Certification report:
Company advantages:
1. Rich product line: We proudly offer a diverse array of agricultural machinery. Our selection includes plows, rotary tillers, disc plows, disc harrows, and deep loosening machines. Explore our sowing machines for crops like wheat, corn, soybeans, and vegetables. For potato and sweet potato planting and harvesting, we've got you covered. We also feature lawn mowers, rakers, balers, and various grass machinery. Enhance your operations with our fertilizer spreaders, sprayers, cultivators, ridgers, excavators, and comprehensive agricultural trailers.
2. R&D and production capabilities: Our cutting-edge facilities boast advanced processing equipment, including laser cutting machines and CNC machining centers. With state-of-the-art welding, assembly, and painting lines, we significantly boost our production and R&D prowess, elevating our equipment standards.
3. International market: Our acclaimed products transcend borders, with a strong presence in Europe, America, Australia, Africa, Southeast Asia, and the Middle East. Valued by domestic and international clients alike, our offerings have earned widespread trust and commendation.
4. Quality control: Committed to delivering state-of-the-art agricultural machinery and unparalleled service, we embrace a diversified procurement strategy for critical components in foreign markets, ensuring products of consistent excellence.
5. Supply Chain Management: We have fostered partnerships with nearly a hundred reliable suppliers across 25 Chinese provinces, cities, and autonomous regions. This bolsters the stability and cost-efficiency of our supply chain, offering robust support to our operations.
6. Corporate philosophy: Guided by principles of 'honesty, trustworthiness, and customer-first service,' we prioritize quality and innovation. Our commitment to independent innovation creates core advantages, strengthening our competitiveness in the agricultural machinery industry.
After sales issues:
For any after-sales concerns, please feel free to reach out to us.
Frequently asked questions:
1. Are you a trading company or a manufacturer?
We are a distinguished manufacturer with a professional edge.
2. What is your delivery time?
For regular stocked items, expect delivery within 7-15 days. For custom or out-of-stock goods, anticipate a delivery timeline of 30-60 days, contingent on order volume.
3. Do you provide samples?
We offer samples for smaller items, whereas large or bespoke items are not eligible for sampling.
4. What are your payment terms?
A 30% down payment is required, with the remaining balance due before shipment.
5. What is your minimum order quantity?
Minimum order quantities vary by product. Please contact us for specific details.
6. How to install the machines after they arrive?
Upon receipt of the goods, we will provide an installation video specific to the product. Follow the video for seamless installation.
7. Can your products be customized?
Customization is available, provided certain conditions are met.
8. How do you ensure the quality of your product?
Our expert team conducts rigorous quality inspections to ensure superior standards.
9. What are the trade terms?
Basically, it's FOB shipping
