High-Efficiency Metering and Mixing Systems for Slurry Applications
| US$100,000.00-10,000,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
KR-ZXAUTO
Application
Liquid, Liquid with Suspended Solids, Powder, Viscous Fluid
Application Area
Agricultural Chemicals, Chemical, Daily Chemical, Engineering & Construction, Food, Metallurgy&Mineral, Pharmaceutical
Certification
CE, ISO
Condition
New
Cooling Method
Water Cooling
Heating Method
Hot Water Heating
Main Material
Stainless Steel
Mixing Drum Shape
Circular Groove
Stirring Type
Spiral
Warranty
1 year
Working
Convection Mixer
Adaptive Process
Vacuum Conveying, Positive Pressure Conveying
Capacity
Positive 300L , Negtive 300L
Whole Line Power
Posive 240kw, Negtive 120kw
Power Supply
50Hz AC 380V Three-Phase Five Wire System
Grounding Resistance
Less Than 4 Ohm
Compressed Air
0.4-0.7MPa 15 M3/Min
Vacuum
Less Than -98kpa Flow Rate Greater Than 15m3/H
Cold Water
Less Than 0.3MPa, Pipe DN50
Usage Area
Indoor
Processing Material Samples
Iron Lithium,Graphite, Conductive Agent,
Usage
Convey Various Material to The Mixer
Powder Density
Less Than 2.5 Moisture Content Less Than 1000ppm
Material Type
PVDF,Cnt, Cme,Diw, Sp,NMP
Container Cleaning
Nitrogen Pulse Pressure Cleaning
Feeding Method
Manual Weighing Vacuum Conveying
Transport Package
Wood Pallet
Trademark
Career
Origin
China
Production Capacity
15000/Year
Product Description
Product Description| Equipment Name | Slurry automation system |
| Applicable process | Vacuum conveying, positive pressure conveying |
| Capacity | Equip equipment according to customer requirements |
| Machine power | According to the equipped equipment |
| Pilot run | Water or actual material |
| Processing material samples | Lithium iron, ternary, PVDF, SP, CMC, graphite, conductive agent |
| Usage | Transport various materials to the mixer |
| Processing powder density | ≤2.5 water content <1000ppm |
| Equipment equipped | Positive and negative electrode main powder feeding system |
| Positive and negative electrode feeding system | |
| Positive and negative electrode filling system | |
| Positive and negative electrode slurry conveying system | |
| Integrated system | |
| Vacuum system | |
| Main equipment details | High viscosity mixer |
| Main powder and auxiliary powder sending tank | |
| Small bag dust-free feeding station | |
| Glue making tank | |
| Glue storage tank | |
| Transfer tank | |
| Measuring tank | |
| Control system | |
| Sand mill | |
| Electrical instruments | Power wiring |
| Sensor | |
| Testing instruments |
Company Profile
Our KR Company, a beacon of innovation, was established in 2006 and proudly operates its headquarters in Dongguan, Guangdong Province, China. As a nationally recognized High-tech enterprise, we expertly integrate research and development, production, sales, and service of advanced intelligent devices. At our core, we specialize in state-of-the-art mixing, drying, grinding, dispersion, and intelligent conveying systems. Our comprehensive product suite encompasses intelligent power mixers, sophisticated vacuum dryers (systems), efficient sand mills, high-speed dispersers, and automated homogenization conveying systems-including powder, liquid, and slurry conveying solutions. Additionally, we offer MES systems and logistics conveying systems specifically designed for the burgeoning field of lithium-ion soft engineering. Our commitment to excellence enables us to provide customers with a seamless, one-stop solution for material processing automation. This includes everything from unpacking and feeding, material storage, and pneumatic conveying, to precise batching, continuous metering, mixing and drying, and advanced mixing and pulping processes. We also specialize in dispersion, grinding, filtration, and dust removal, right through to finished product packaging and intelligent control systems. Our products are celebrated for their versatility, serving a myriad of industries such as new energy, chemicals, fine chemicals, daily chemical products, food, medicine, ceramics, coatings, adhesives, and more. We pride ourselves on meeting the personalized customization needs of our diverse clientele, ensuring that every piece of equipment is tailored to perfection.
