Automatic Exchange Table Fiber Laser Cutting Machine for Sheet Metal

Automatic Exchange Table Fiber Laser Cutting Machine for Sheet Metal

US$23,860.00-40,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
H-6025D
Application
Petroleum Machinery Manufacturing, Agriculture Machinery, Aerospace Industry, Automotive Industry, Advertising Industry
Cooling System
Water Cooling
Technical Class
Pulse Laser
Applicable Material
Metal
Structure Type
Gantry Type
Laser Classification
Solid Laser
Power
1kw/2kw/3kw/4kw/6kw
Motor
Delta/Yaskawa Servo Motor
Reducer
Japan Reducer
Laser Generator
Gw/Raycus/Ipg
Controller
Au3tech/Cypcut
Package Gross Weight
2500kg
Transport Package
Export Wooden Box
Specification
620*230*180cm 2500kg
Trademark
hsd
Origin
China
HS Code
8456110090
Production Capacity
100 Pieces/Month

Packaging & Delivery

Package Size
620.00cm * 230.00cm * 180.00cm
Package Gross Weight
2500.000kg

Product Description

Automatic Exchange Table Fiber Laser Cutting Machine for CNC Sheet Metal
Product Description
1. Intelligent automatic focusing laser head
Automatic focusing mode of the laser head reduces human interference with a focusing speed of 10m/min and repeated positioning accuracy of 50um.
2. Aircraft-grade aluminum crossbeam
Aircraft-grade aluminum is corrosion resistant, lightweight and highly rigid, guaranteeing high speed laser cutting. Besides, it also guarantee the excellent cutting precision due to the perfect dynamic performance such as anti-twisting, anti-tilting and anti-deformation.
3. High quality thick wall carbon steel pipe welded bed
High strength machine bed is more stable and durable. After 600ºC stress relief annealing treatment, the machine bed has strong structural rigidity. The overall mechanical structure of the machine has small deformation, low vibration, ensure cutting accuracy.
4. Integrated large volume dust removal system
The dust removal system can remove all the smoke generated from the cutting process with large air volume. This helps protect the operator's health and the working environment.
5. Automatic lubrication system
Automatic lubrication method saves more human labor, reduces maintenance time, and greatly improves work efficiency.
Product Features
1. High rigidity of the machine tool bed, exclusive high temperature control standard furnaces annealing treatment, can guarantee the precision of the machine tool is stable for a long time does not change.
2. Imported original fiber laser generator with good beam quality, stable performance, no reflector lens, no need to adjust the optical path, basic maintenance free, service life can reach more than 10 hours;
3. Fiber laser with high Electro-optical conversion efficiency, conversion efficiency of 30%, the power consumption can be saved greatly when working.
4. Adopts imported original guiding drive and servo motor, high precision, high speed;
5. Supported all kinds of graphic format or text instant cutting, simple operation, flexible and convenient.
6. Beautiful, smooth cutting edge,without deformation;
7. Low energy consumption, energy saving and environmental protection, low power consumption, the power consumption is VAG with the power consumption of 1/3-1/5, cutting speed of YAG is more than three times;
8. Without working gas lasers, air available for sheet cutting ;
9. Fast cutting speed, low operation cost,investment recovery quickly;

Application
sheet metal cutting, pipe (needs to add another tube cutting device):stainless steel, carbon steel, galvanized sheet, electrolytic plate, brass, aluminum steel, manganese, all kinds of alloy plate,rapid processing and so on.
Configuration
No Item QTY Brand
1 Laser Source 1 IPG/Raycus/Max
2 Laser Head 1 Switzerland Raytools
3 Control System 1 Cypcut
4 Machine Bed 1 16-25mm Welded Steel Panel
5 CNC or Not 1 Yes
6 Pneumatically Part 1 SMC
7 Guiding Rail 1 Taiwan Hiwin 35mm
8 Helical Rack 1 Taiwan YYC 3mol
10 Nesting Software 1 /
11 Motor 1 Yaskawa Servo Sigma 7
12 Reducer 1 France Motorvario
13 Water Chiller 1 Hanli(Option: Tongfei)
14 Air Compressor 1 Chinese brand
15 Dust Extraction 1 Acme
16 Waste Collection 1 Trolley for material shorter than 250mm

Parameters
Model HM-6025
Working area 6000*2500mm
Optional Working Area 1300*2500mm, 2000*3000mm, 2000*4000mm, 2000*6000mm,..
Configuration Specifications
Laser Generator GW/Raycus/IPG
Laser Cutting Head Au3tech, Raytool,
CNC Controller Au3tech, Cypcut
Servo driver system Delta/Yaskawa/Pansonic
Speed Reducer Shimpo Reducer, Japan
Rack and Pinion: Taiwan CSK/TBI/HIWIN guide rails
Max.cutting speed 0-30m/min(Depending on the material and thickness)
X, Y, Z Axis Repeat PrecisionX, Y, Z Axis Repeat Precision ≤±0.03mm /m
Min line width ≤0.15mm
Maximum Empty Running Speed 120m/min
Driving way Imported servo motor
Transmission way Y-axis import gear rack double driver, X-axis imported ball screw
Cooling System Water Cooling
Continuous working time 24 Hours
Power requirements 380V/3 Phases /50Hz or 60Hz


Product Details
Raycus/Max/IPG Laser Source
Most famous laser source brand in China.
Fiber laser is compact in structure, stable in performance and widely used, Fiber laser has high photoelectric conversion efficiency, good beam quality and low maintenance cost.
Muitiple choice different power brand, and different power are available. The higher power , thicker cutting thickness.
Welded Bed The constant temperature of water chiller can keep the laser power stable,work more stable and fast
Which is welded by a number of rectangular tubes. Stiffeners are arranged inside the tubes to increase the strength and tensile strength of the bed, it also increases the resistance and stability of the guide rail so as to effectively avoid the deformation of the frame.
High strength, stability, tensile strength, ensuring 20 years of use without distortion
Aluminium Gantry
High hardness Aerospace aluminum is manufactured with aerospace standards and extruded in a 4,300 ton press. The hardness can reach T6 after processing.
High speed Aviation aluminum has the features like good toughness, light weight, corrosion resistance, oxidation resistance and low density, which greatly improve the processing speed.
Laser Head
Including: Manual Focusing and Automatic Focusing,More and more fiber laser cutting machine use automatic focusing laser head.
The software automatically adjusts the focusing lens to realize automatic perforating and cutting plates of different thickness.
The speed of automatically adjusting focus lens is ten times of the manual adjusting.
Bigger Adjustment Range
Adjustment range -10 mm~ +10mm, precision 0.01mm, suitable for 0 ~ 20mm different types of plates.
Long Life Time
Collimator lens and focus lens both have water-cooling heat sink which reduces the temperature of the cutting head to improve the life of the cutting head
Japan Yaskawa servo motor and drive
-More accurate
It realizes closed-loop control of position, speed and torque; overcomes the problem of stepping motor out of step;
-Rotating speed is more faster
High speed performance, general rated speed can reach 2000~3000 rpm;
-Daptability
High strong anti-overload capability, load three times the rated torque, suitable for occasions with transient load fluctuations and fast start required;
-Stable
Smooth operation at low speed, no stepping operation similar to stepper motor when running at low speed.
Samples Show
Our service
1. For whole fiber laser cutting machine, we provide 2 years warranty and lifetime after-sales service, we will provide the consumable. parts at an agency price when you need replacement.
2. Main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
3. Our engineer could support you technology to your country if necessary.
4.Our engineer could service you 24 hours online by Skype, WhatsApp, msn, or by cellphone.
5. English manual and CD video for machine using and maintaining will send to you with the machine.
