Diesel Mini Dumper 800 Kg Factory Price with Kubota Engine EPA European

Product Description

1.Why choose us?TOBEMAC----CHINA Leading Construction Machinery Manufacturer We are manufacturer of Concrete Mixers Since 1991. We are certified by SGS;BV;SONCAP;PVOC;CE; ISO 9001:2015 We have a Professional Construction Machinery workshop which covers an area of 10000 sqm and its daily output for SITE DUMPER is 50 sets , so we can assure you the punctual delivery. Our main products include all kinds of Diesel Concrete Mixer,Electric Concrete Mixer,Concrete Mixer Truck, Hoisting Machinery, Road Machinery,Compactor Machinery,Block Machinery , and etc. Our company is near the NINGBO port , you are very welcome to come to our company. 2.Products Specification:

	Model:MD300	Model:MD500	Model:MD500A	Model:MD1000
Engine	Loncin 196cc	Briggs/Stratton	Loncin 270cc	koop KD 192F
Cooling mode	Air-cooled	Air-cooled	Air-cooled	Air-cooled
Fuel	Gasoline	Gasoline	Gasoline	Gasoline
Emission	Euro5	EPA4	Euro5	Euro5
Transmission	Forward:6/Rear:2	/	Forward:6/Rear:2	Forward:3/Rear:1
Speed type	High-Low	/	High-Low	/
Loading capacity	300kg	500kg	500kg	1000kg
Box length	1045mm	816mm	816mm	1250mm
Box width	630mm	680mm	680mm	890mm
Box depth	320mm	620mm	620mm	480mm
Box type	Split type	Integrated/one-piece	Integrated/one-piece	Integrated/one-piece
Track width	180mm	180mm	180mm	230mm
Flow of pump	/	6L/min	3L/min	/
Min Dumper weight	281kg	413kg	316kg	682kg
Oerall dimension(mm)	1980*820*1060	1680*840*1275	1750*700*1080	2310*950*1345
Start mode	Manual	Manual	Electric	Electric
Loading quantity	12sets/20GP	14sets/20GP	18sets/20GP	6sets/20GP
	24sets/40HQ	28sets/40HQ	36sets/40HQ	12sets/40HQ

3.Our service
1.Installation, debugging, operators trainning;
2.Maintanence:
A. when trainning your operators, our engineers will give them advice on how to operate the machines correctly;
B. we will send you the operation manual which can help you operate the machins properly, it can also help you to solve the common problems;
C. Call us at any time if you have problems about our concrete mixers;
D. If needed, we will send engineers to your site to solve your problems.
3.Providing some documents needed for your customs clearance, like commercial invoice, packing list, certificate of origin etc;
4.Spare parts supply;
