Auto Feed Drilling Machine Z5025A Z5030A Z5032A Z5035A Z5040A Z5050A

Auto Feed Drilling Machine Z5025A Z5030A Z5032A Z5035A Z5040A Z5050A

US$2,500.00-4,000.00 1 Piece (MOQ)

Basic Info.

Model NO.
Z5025A Z5030A Z5032A Z5035A Z5040A Z5050A
Structure
Vertical Drilling Machine
Layout
Vertical
Controlling Mode
Artificial
Number of Shaft
3
Hole Diameter
<50mm
Automatic Grade
Manual
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Max. Driiling Capacity
30mm
Max. Taping Capacity
M18
Max.Spindel Travel
135mm
Spindle Bore Taper
Morse 3
Spindel Speed
70-2600rpm
Column Diameter
125mm
Motor Power
1.1/1.5kw
Transport Package
Plywood Case
Specification
Cast Iron
Trademark
HOYONG-TRD
Origin
Shandong, China
HS Code
845929000
Production Capacity
300

Product Description


Vertical Drilling Machine Features:
The machine is designed with multi-function of drilling. Broaching, reaming, tapping and facing milling.
With a strengthened capacity of drilling it allows the workpieces to be drilled with larger range of size.
It is suitable for using in both production and maintenance shops
1. Easy operation.
2. Casting iron structure for long durability.
3. Column type of vertical drilling machine.
4. Worktable can tilt 45degree
function of drilling. Broaching, reaming, tapping and facing milling.
With a strengthened capacity of drilling it allows the workpieces to be drilled with larger range of size.
It is suitable for using in both production and maintenance shops
1. Easy operation.
2. Casting iron structure for long durability.
3. Column type of vertical drilling machine.
4. Worktable can tilt 45degree
SPECIFICATIONS:
MODEL Z5030A Z5035A Z5040A Z5050A
Max. drilling capacity(mm) 30 35 40 50
Max. taping capacity(mm) M18 M20 M24 M24
Distance from spindle axis to
generating line of column(mm)
315 330 360 360
Max. distance from spindle nose to
work table surface(mm)
520 610 600 600
Max. distance from spindle
nose to base(mm)
1080 1150 1215 1205
Max. spindle travel(mm) 135 150 180 180
Max. adjustment of work
table and table rest(mm)
480 540 560 525
Swivel of table and table reat ±45° ±45° ±45° ±45°
Spindle bore taper(Morse) 3 4 4 4
Spindle steps 12 12 12 12
Spindle speed(r/min) 70-2600 70-2600 42-2050 42-1685
Spindle feed steps 3 3 4 4
Spindle feed range(mm/r) 0.1,0.2,0.3 0.1,0.2,0.3 0.07,0.15,
0.26,0.4
0.07,0.15,
0.26,0.4
Column diameter 125 140 160 170
Effective area of table(mm) 450x450 500x550 580x450 580x450
Effective area of base plate(mm) 690x480 760x500 820x550 820x550
Dimension of T-slot (mm) 2-14 2-16 2-14 2-16 2-14 2-16 2-14 2-16
3-phase tea-speed AC motor Power(kW) 1.1/1.5 1.5/2.2 2.2/2.8 2.2/2.8
3-phase pump motor Power(kW) 0.09 0.09 0.09 0.09
Packing size(mm) 650x1050x1950 700x1150x2150 700x1150x2150 700x1150x2150
