Automatic Bottles Trigger Flip Pump Cap Capping Machine

Product Description

Product Description
It is characterized by its reasonable compact, convenient operation and maintenance, linear entrancing and positioning. It is not only suitable for PE cap,andPEX-al-PEX cap but also the duck cap and caps which with nozzle. its adaptability is very good. It is widely used in pharmacy, pesticide, sauces, condiments, industries etc. The pneumatic and electric components we used in this machine are world-renowned brand, it is very reliable and durable.
Technical parameters:
Screwing head: 1 head(4 wheels)
Model: CHLR-25
screwing speed:1500-2200bottles/h
diameter of the bottle body: 30-110mm(customized)
diameter of the cap:60-100mm
power: 220V,50Hz single phase
Height of the bottle: 50-280mm
power: 300w
air pressure: 0.7Mpa 0.3m3/min
weight: 300kg
outside size: 1800*700*1700mm

Main part	Brand
PLC controller	Taiwan Delta
Touch screen	Taiwan weiview
Sensor	Korea AUTONICS
Conveyor motor	Taiwan OTG

Packaging & Shipping
After Sales Service
The above machine which we supply it to you, we can give you one years after sales warranty, we can also send our engineer to you factory to install this equipment and train your staff, but the Buyer should pay the round air ticket cost and arrange the hotel accommodation as well as the means for Seller's engineer. We will send some free set of spare parts for you change it.
Payment terms:
40% deposit by T/T before production, 60% balance should be paid by T/T before shipment, we also accept L/C payme.
Package:
Standard wooden Case Packing
Shipment terms:
We usually take FOB, but we can also accept EXW,CIF,CNF.
