18000lbs Electric Powerful 24V Winch with Remote Control
Basic Info.
Model NO.
X18000
Pull Direction
Forward
Electric Winch Model
Jeep
Working Voltage of Electric Winch
Low Voltage
Brand
Zhme
Applicable Environment
off-Road
Certification
CE, SGS
Gear Train
3-Stage Planetary Gear
Transport Package
1 Winch/ CTN, 15 Ctns/ Pallet
Specification
N. W. 60kg
Trademark
ZHME
Origin
Zhejiang, China
HS Code
84253190
Production Capacity
10000 PCS Per Year
Packaging & Delivery
Package Size
70.00cm * 30.00cm * 40.00cm
Package Gross Weight
60.000kg
Product Description
| Specification | ||||||
| Rated line pull: | 18000Lbs (8165kgs) single line | |||||
| Motor: | Series wound 6.8 hp /5.0kw, 12V DC | |||||
| Gear Train: | 3 stage planetary | |||||
| Gear ratio: | 345:1 | |||||
| Clutch: | Sliding Ring gear | |||||
| Braking action: | Automatic in the drum | |||||
| Fairlead: | Roller fairlead for wire rope | |||||
| Wire rope: | 11.5mm ×28m | |||||
| Drum size: | 3.5"×8.8"(88mm×224mm) | |||||
| Dimensions: | 23.9"×8.5"×9.4"( 608mm×216mm×239mm) | |||||
| Mounting bolt pattern: | 10"×4.5"(254mm×114.3mm) | |||||
| Battery: | Recommended 650 CCA minimum for winching 25 square mm,72"(1.83m) | |||||
| N.W: | 132lbs (60kgs) | |||||
| Packing: | 700mmx300mmx400mm (300pcs per 20' container) | |||||
| Line speed and motor current (first layer) | ||||||
| Line pull | Lbs | 0 | 2000 | 6000 | 12000 | 18000 |
| Kgs | 0 | 907 | 2722 | 5443 | 8165 | |
| Line speed | FPM | 19.7 | 12.5 | 8.2 | 6.2 | 3.8 |
| MPM | 6 | 3.8 | 2.5 | 1.9 | 1.1 | |
| Motor current | Amps | 70 | 120 | 200 | 290 | 440 |
| Line pull and cable capacity | ||||||
| Layer of cable | 1 | 2 | 3 | 4 | ||
| Rated line pull per layer | Lbs | 18000 | 15300 | 13580 | 10560 | |
| Kgs | 8165 | 6940 | 6160 | 4790 | ||
| Cable capacity per layer | Ft. | 17.6 | 37 | 63 | 85 | |
| M | 5.4 | 11.4 | 19.4 | 26 | ||
