Best Selling Jet Self-Priming High Pressure Big Flow Low Noise High Quality Clean AC Water Pump

Product Description

Pump
>> Pump Body: cast iron & support under special anti-rust treatment
>> Impeller: stainless steel impeller, brass impeller, ppo impeller
>> Mechnical Seal: carbon / ceramic / Stainless Steel
>> Diffuser: PPO/ABS
Motor
>> Bulit-in thermal protector for single phase motor
>> Motor with copper winding
>> Motor Housing: Steel-plate, Aluminum alloy
>> AISI 304 shaft or 45# carbon steel
>> Insulation: f
>> Protection: IP44, ip54 optional
Working Range
>> Liquid: clean liquids without suspended solids, non-aggressive
>> Liquid temperature: up to +40ºC
>> Ambient temperature up to +40ºC
>> Max. working pressure 8bar
>> Continous service S1
JET-S Self-priming pumps
1. Self-priming: For the first time using, the entire pump chamber should be filled with water.
2. Booster: Stable and powerful pressure is controlled by pressure sensor and flow sensor.
Besides, thermal protector in motor will interrupt current when motor overheats.
TECHINICAL DATA AT 220-240V/50HZ

MODEL	POWER		MAX.FLOW	MAX.HEAD	MAX.SUCT	INLET/OUTLET	GW	PACKING DIMENSION(MM)
	kW	HP	(l/min)	(M)	(M)	(inch)	(kgs)
JET-60S	0.37	1/2	40	35	9	1" x 1"	13.2	415*215*230
JET-80S	0.55	3/4	45	40	9	1" x 1"	14	415*215*230
JET-100S	0.75	1	50	45	9	1" x 1"	14.8	415*215*230

Note: 110V/60HZ, 115V/60HZ, 127V/60HZ, 110/220V/60HZ, 380V/50HZ ets. Models are available on request.
PACKING WAYS
SPARE PARTS:
FAQ Q: Are you trading company or manufacturer ? A: We are factory.
Q: How long is your delivery time? A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ? A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ? A: T/T, L/C
