Digital Portable Oil Fuel Dispenser Flow Meter Station Feed System Portable Diesel Unloading Gravity with Qquick Connector Liquid Turbine Flow Meter
| US$1,000.00-2,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
Turbine flow meter
Accuracy
±0.2-0.5%
Main Application
Diesel Fuel, Fuel Oil
Size
DN50-100
Sensor
Tube/Flange
Application
Petroleum Industry
Type
Turbine Flow Meter
Measuring Media
Liquid
Measuring Principle
Mechanics
Measurement Object
Closed Pipeline
Certification
GB, CE, ISO, TUV,CMC
Product Name
Portable Turbine Flow Meter
Model No.
TM-80
Body Material
Aluminum
Flow-Rate (Range)
130-1300L/Min
Working Pressure
0.05MPa
Power Supply
DC12-24V, 3.7V Lithium Battery
Rotor Material
2Cr13 Stainless Steel, Alloy CD4MCU
Package Gross Weigh
28kg
Transport Package
Carton
Specification
DN80 3"
Trademark
Virette
Origin
Nanjing, China
HS Code
9026100000
Production Capacity
999set/Month
Packaging & Delivery
Package Size
74.00cm * 50.00cm * 35.00cm
Package Gross Weight
18.000kg
Product Description
| Technical parameters | |
| Product name | Portable turbine flow meter |
| Model NO. | TM-80 |
| Body Material | Aluminum |
| Flow-Rate (Range) | 130-1300L/Min |
| Working Pressure | 0.05Mpa |
| Accuracy | ±0.2% |
| Specification | DN80 3" |
| Power Supply | DC12-24V, 3.6V Lithium Battery |
| Protection Level | IP 65 |
| Certification | CE,ISO,CNEX,TUV,CMC |
| Rotor Material | 2Cr13 Stainless Steel, Alloy CD4MCU |
| Package Gross Weigh | 28Kg |
| Working Temperature | -20 - 120 Deg.C |
| Signal Output | Pulse,4-20mA, RS 485 |
FAQ:
Q1:Are you factory or trading company?
A:We are a production factory with 30 years of production experience, equipped with a professional sales team and after-sales team.
Q2:What kind of product do you make?
A:We produce professional fuel dispenser, LPG dispensesr, CNG dispenser,Mobile fuel dispenser, Pump, flow meter, nozzle, etc.
Q3:Can you supply customized service?
A:Yes.
Q4:Is that your fuel dispenser easy to operate?
A:Yes, each fuel dispenser packed together with one guide book to help you get more info. of our fuel dispenser, guide you operate in the correct way, and future maintain.
Q5:What can we do if we meet problem and need technical consulting?
A:Please give us detail of problem you have, any picture or video will be more better to help us find a solution for you.
