Horizontal Self Suction Priming Chemical Slurry Centrifugal Sewage Clean Water Pump

Product Description

Household Brushless Surface Centrifugal Solar Vortex Water Pump for Domestic Product Description
Product Use:
The series of electric pumps because of small size light weight specially for the majority of rural underground pumping irrigation aquaculture water supply and drainage garden pouring and hotels,can teenshigh-rise buidings and other places for water use.
Service Conditions:
The water temperature is less than +40ºC;
PH value between 6.2-8.5
The water containing solid impurities than not more than 0.1%particle size is not greater than 0.2m
Product Parameters

MODEL	POWER		Q m³/h	0	0.6	1.2	1.8	2.4	3	3.6	4.2	4.8	5.4	6	6.6	7.2	7.8	8.4	INLET/OUTLET	N.W	LxWxH
	kw	HP	Q L/min	0	10	20	30	40	50	60	70	80	90	100	110	120	130	140	(Inch)	(kg)	(mm)
CPM130	0.37	0.5	H(m)	20	18.5	17	15.5	14	12	10									1" x1"	8.5	270x190x240
CPM146	0.55	0.75		26	25	24	23	21.5	20	18.5	17	15	13	10.5	7.5				1"x1"	11.5	320x200x255
CPM158	0.75	1		32	30.5	29	27.5	25.8	24	22.5	20.5	18.5	16	13	10				1"x1"	13.5	320x215x270
CPM180	1.1	1.5		36	35	34	33	31.5	30	28.5	26.5	25	23	20.5	18	15.5			1"x1"	20	380x265x325
CPM190	1.5	2		41	40	39	38	36.5	35	33.5	32	30	27.5	25	22	18.5	15		1"x1"	21	380x265x325
CPM200	2.2	3		44	43	42	41	39.5	38	36	34	32	29.5	26.5	23.5	20.5	17	14	1" x1"	22	380x265x325
CPM130-1	0.37	0.5		20	18.5	17	15.5	14	12	10									1"x1"	9.5	280x190x230
CPM146-1	0.55	0.75		26	25	24	23	21.5	20	18.5	17	15	13	10.5	7.5				1"x1"	13	320x200x255
CPM158-1	0.75	1		32	30.5	29	27.5	27.5	24	22.5	20.5	18.5	16	13	10				1" x1"	15.5	320x215x270
CPM130-2	0.37	0.5		20	18.5	17	15.5	14	12	10									1"x1"	8	290x190x240
CPM158-2	0.75	1		32	30.5	29	27.5	27.5	24	22.5	20.5	18.5	16	13	10				1"x1"	12	310x220x270
CPM180-2	1.1	1.5		36	35	34	33	31.5	30	28.5	26.5	25	23	20.5	18	15.5			1"x1"	18	400x240x290
CPM190-2	1.5	2		41	40	39	38	36.5	35	33.5	32	30	27.5	25	22	18.5	15		1"x1"	19	400x240x290

Detailed Photos
Company Profile
Zhejiang MingBa Mechancial&Electrical Co., Ltd. Located in Wenling city of Zhejiang province which is not only the biggest water pumps production base of China, but also the most famous town of pump production all over the world. After 20 years development, our annual production capacity reaches to 1500, 000 sets. MingBa is the leader pump enterprise in Taizhou. Our company established new modernize standard factory plants cover 18000 m3 in wenling eastern industrial areas and is professional for manufacturing submersible and sewage pumps, we are fight for realizing 3, 000, 000 sets production goal.
MingBa is one of the drafting enterprises of National standard for submersible pump. In 2000, we earned the ISO9001: N. We also gained CCC, CE and RoHS certifications. MingBa is be honored with High and New Technology companies by Zhejiang government.
FAQ
Q1: How about the quality?
A: We use high quality raw material for production, and 100% QC in producing process before the goods being packed up. we sincerely expect to work with you for long and stable time.
Q2: What's your warranty?
A: One year warranty, detail as your requirement.
Q3: Could I put my own logo on it?
A: Definitely, we can make your logo after you give us your authorization.
Q4: What's your payment term?
A: 30% deposit before producing, 70% TT against BL copy.
Q5: Can I get a sample to check your quality and how long i can get samples?
A: Definitely,sample will be finished within 7-14 days.
Q6: How about the delivery time?
A: 30-45 days after receipt of deposit.
