High Output Fully Automatic Plastic Pet 5 Gallon Small Mineral Water Bottle Preform Making Injection Molding Moulding Machine

High Output Fully Automatic Plastic Pet 5 Gallon Small Mineral Water Bottle Preform Making Injection Molding Moulding Machine

US$25,000.00-28,500.00 1 Set (MOQ)

Basic Info.

Model NO.
SE-230T/IP
Type
Injection Blow Molding
Structure
Horizontal
Plastic Type
Thermoplastic
Plasticizing Way
Screw Type
Clamping Way
Hydraulic & Mechanical
Automation
Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008
Product Name
Plastic Injection Molding Machine
Product
Horizontal Injection Molding Machine
Injection Rate
361cm³/Sec
Weight
7300kg
Motor Power
30kw
Advantage
Durable
MOQ
1 PCS
Transport Package
Wooden Case
Specification
6.2*1.4*2.2m
Trademark
ENJI
Origin
Zhejiang, China
HS Code
847710109
Production Capacity
150 Pieces One Year

Product Description

Automatic Bottle Preform Injection Blow Molding Making Machine for Plastic Products
Product Parameters
Se-230T/IP Plastic Injection Molding Machine Information
Item Unit A
B
C
Screw diameter mm 60
Theoretical shot volume cm³ 707
Shot weight (PET) g 820
Shot weight (PET) oz 28.9
Length/Diameter ratio L/D 25
Injection pressure Bar 1293
Injection rate cm³/sec 361
Max.screw speed rpm 200
Clamping force KN 2300
Max.daylight mm 820*770
Open stroke mm 520
Space Between Tie-bars mm 570*520
Min mould dimension mm 220
Mould thickness range mm 570
Ejector force KN 90
Ejector stroke mm 150
No.of ejector pins unit 9
Max.motor power KW 30
System pressure MPa 175
Heater input power KW 22
Oil filling capacity L 200
Machine size M 6.2*1.4*2.2
Net weight KG 7300

SE/IV series machine advantages
Distributed architecture (n-tier);
TCP / lP efficient network connection,Internet remote control;
Synchronous cluster status browsing and parameter central control;Real-time heating curve to monitor barrel temperature changes.
Temperature and molding parameter statistics to assist in quality management.Expansion of the die storage space for mutual replication.
Scalability. providing interface with ERP.
Operator password rights management, recording of modification logs.Ease of operation and support for multiple languages.
Detailed Photos
