China Xuzhou Manufacture Crawler Excavator Xe690dk 65t Mini Crawler Excavator

Product Description

Product Description
XE690DK is equipped with a reinforced large undercarrage and high-power travel reducers for mine operation. Ultra long warranty period, greatly reducing the whole life maintenance cost of the excavator. A variety of attachments are provided to match the requirements of different working conditions.

Product Parameters

SPECIFICATION OF XE690DK 65T CRAWLER CRANE
Item	Unit	Parameter Value
Model	-	XE690DK
Operation Performance Parameter
Operating weight	kg	65800
Bucket capacity	m³	3.8-4.5
Bucket digging force	kN	382
Arm digging force	kN	318
Max. digging height	mm	10379
Max. digging reach	mm	7287
Max. digging depth	mm	6893
Engine Parameter
Model	-	WEICHAI
Rated power/speed	kw/rpm	566/2100
Maximum torque/speed	N.m	3000/1500
Displacement	L	16.72
Dimension Parameter
Crane Full Dimension(L×W×H)	mm	11388*3390*3570
Width of Crawler	mm	3030
Speed Parameter
Travel speed(H/L)	km/h	4.9/2.9
Swing speed	r/min	7.3
Gradeability	°	35

Detailed Photos

Company Profile
HOKA VEHICLE is located in Shanghai, which is a financial, trade and shipping center in China. All these give our company an obvious superiority in trade, transportation and material flow.
With the professional team, first class design, production experience and market capacity, HOKA VEHICLE has exported and delivered more than 5, 000 units Construction Machinery to countries across Africa Middle East, Southeast Asia and South America.Our main products cover more than 11 series, ranging from Hoisting Machinery, Building Machinery, Earthmoving Machinery, Concrete Machinery,Road Machinery,Logistics Machinery, Trucks, Drilling Machinery, Mining Machinery and all other kinds of Construction Machinery.
