AU-3000K Digital Electronic Gold Testing Equipment Metal Density Measuring Instrument Purity Test Machine

Product Description

AU-3000K Digital Electronic Gold Testing Equipment Metal Density Measuring Instrument Purity Test Machine

Application

pawnbroking,jewelry industry,banking industry,jewelry testing center,mining industry,precious metal recycling,precious metal materials researching laboratory.,etc.

These series instrument gold tester is the dramatic updating and upgrading products.Compared with other competing products,it has been focused on enhancing weighting resolution,simplified operation procedure and operation method,upgraded software application function,improved reliability of measuring result. offer respectively three content measuring model for gold,platinum,silver and one alloy measuring model;

No need to bundle samples.Following value can be displayed precisely and quickly with only two procedure:
(1) karat value,percentage content,density for gold
(2) PT value,percentage content,density for platinum
(3) S value,percentage content,density for silver
(4) percentage content,density for other alloy.


Measuring Type

Precious metal.such as gold,Karat gold,platinum,silver.
Mixed metal or other alloy metal.
Jewelry materials.such as ring,necklace,bracelet,watchband,belt fastener,gold ingot,gold bar,statue,coin.,etc.
Notes:
Please check the samples to be tested firstly when do testing:
(1). products of which inside is hollow
if the hollow is closed.water or other liquids can't get access into,the samples can't be tested
if the hollow is opened,water or other liquids can get access into,the samples can be tested
(2). products set with precious stones------can't be tested
(3). products of which the density is very close to precious metal------can't be tested


Features

Distinguish whether the gold,karat gold,platinum,silver,other precious metal is the genuine or not. Test the purity of gold,karat gold,platinum,silver to confirm if the marked content is correct or not. No need to cut samples;also it can be measured immediately. Can shift to measure Karat and purity percentage of gold-silver -copper,gold-copper,gold-silver respectively. Function of density measuring and normal gram scale. Either water or alcohol would be as medium. Function of setting actual water temperature. Adopt completed injection molding PC sink(length:15.3cm X width10.7cm X 9.3cm) Including RS-232 interface;It's convenient to connect PC and printer.AU-40 could be optionally availabe to print result. Adopt injection moulding windproof dustproof shield;Convenient configuration;Better durability. Power supply:AC 100V-240V;50HZ/60HZ(Europe standard) Weight/packing size:4.5kg/length 42.5cm X width 17.5cm X height 32.5cm
Measurement Resolution And Range

AU-300K weighting resolution:0.005g,minimum weight:4g,density resolution:0.001g/cm3 AU-600K weighting resolution:0.005g,minimum weight:4g,density resolution:0.001g/cm3 AU-120K,200K weighting resolution:0.001g,minimum weight:2g,density resolution:0.001g/cm3 900K,1200K,2000K,3000K weighting resolution:0.01g;minimum weight:5g;density resolution:0.001g/cm3 K value range:9k,10k,11k,12k,13k,14k,15k,16k,17k,18k,19k,20k,21k,22k,23k,24k and % percentage content. Platinum content range:PT600,PT650,PT700,PT750,PT800,PT850,PT900,PT950,PT1000 and % percentage content. Silver content range:S600,S650,S700,S750,S800,S850,S900,S950,S1000 and % percentage content. The proportion of copper-silver for gold-silver-copper can be shifted cyclically with 9/1,8/2,7/3,6/4,5/5,4/6,3/7,2/8,1/9.the default setting is 7/3.
Measuring Procedure

(1)Measure the weight in air firstly,press ENTER button.
(2)Place the sample into water to measure weight in water.Press ENTER button.display result.

Standard Accessories

(1)Host,(2)Sink,(3)Measuring plate,(4)Tweezers,(5)Thermometer,(6)weight,(7)windproof dustproof cover(8)One set of measuring gold dust accessories(9)Power supply


Specification Table

Brand	Quarrz
Model	AU-300K / AU-600K / AU-900K	AU-120K / AU-200K	AU-1200K / AU-2000K / AU-3000K
Style	Hot and Classic	High-precision	High-capacity
Maximum weight	300g / 600g / 900g	120g / 200g	1200g / 2000g / 3000g
Weight standard deviation	0.005g / 0.005g /0.01g	0.001g	0.01g
Minmum measuring sample Reference weight	4g / 4g / 5g	2g	5g
Density resolution	0.01g/cm3	0.001g/cm3	0.001g/cm3
Sink size	Length15.3 cm×width10.7 cm×height9.3cm		Length20.3 cm×width15.7 cm×height11.3cm
Measuring function	(1)karat value,percentage content,density for gold (2)PT value,percentage content,density for platinum (3)S value,percentage content,density for silver (4)percentage content,density for other alloy.
Gold K value	(9 ,10,11,12,13,14,15,16,17,18,19,20,21,22,23,24)K &content percentage %
Platinum	PT600 ,PT650,PT700,PT750,PT800,PT850,PT900,PT950,PT1000 & content percentage %
Silver	S600 ,S650,S700,S750,S800,S850,S900,S950,S1000 & content %
Measuring principle	Archimedes buoyancy method
Measuring time	About 5 to 20 seconds
Measuring procedure	(1)Measure the weight in air firstly,press ENTER button. (2)Place the sample into water to measure weight in water.Press ENTER button.display result.
Parameter setting	Water temperature setting,measuring medium density setting,air density setting,main materials and secondary materials density setting,copper-silver proportion setting
Copper-silver proportion range	can be shifted cyclically with 9/1,8/2,7/3,6/4,5/5,4/6,3/7,2/8,1/9.the default setting is 7/3.
Calibration method	Single button calibration,automatic testing
Standard accessories	(1)Host,(2)Sink,(3)Measuring plate,(4)Tweezers,(5)Thermometer,(6)weight,(7)windproof dustproof cover(8)One set of measuring gold dust accessories(9)Power supply
Data interface	Standard RS-232 interface
Optional accessories	AU-40 printer,AU-40A data connecting line
Power supply	AC100V~240V 50HZ/60HZ Europe standard
Gross weight/size	4.3kg/ Length 42.5 cm× width 17.5 cm×height 32.5cm (no including weights)

Advantage For Quarrz's Precious Metal Tester Gold Tester

Wide karat value for gold display from 9K to 24K and % percentage content. Wide PT value for platinum display from PT600 to PT1000 and % percentage content. Wide S value for silver display from S600 to S1000 and % percentage content. Adopt completed testing board and unobstructed without lifting lid design,more simpler operation,also makes the measuring result more reliable. Two procedure; No need to bundle samples.It is convenient for multiple testing. No stains or scratches will be left on samples after tested Multi-function as density meter and gram scale. Upgrade circuit board;make the testing result more stable and reliable. Testing frame has been improved;more larger measuring space. Equiped with windproof cover.
Understanding Karats

Since gold is a soft metal, it's often combined with other harder metals when it's used in jewelry to provide durability. In general,gold is mixed with silver and copper(Except 24K pure gold).Gold jewelry is measured in 24 parts, called karats (K), to indicate how much of the piece is pure gold. So, if gold is 24K, all 24 parts of the jewelry are gold. Jewelry marked 22K is 22 parts gold, two parts harder metals.which means,the jewelery including 22/24(91.67%) gold,the remaining 2/24(8.3%) belongs to copper-silver mixure,or copper,or silver.Thus, the lower the number, the less gold. As such, 24K gold is the softest, while 10K is significantly the harder.Our machine can test the K value,density,purity percentage for mixure gold-copper-silver,gold-copper,and gold-silver.for jewellery manufacturer,the ratio of gold-silver-copper can be set freely to get the exact K value,density,purity percentage.
