500W 1310-1550nm Single Mode Optical Fiber Isolator

Product Description

500W 1310-1550nm Single Mode Optical Fiber Isolator
Product Description Features
Low Insertion LossHigh Return LossHigh Stability & ReliabilityHigh lsolationApplications
Test InstrumentFiber Optical LaserMOPA Fiber Optical LaserPM Optical Fiber AmplifierSpecifications

Parameter	Unit	Spec
Center Wavelength	nm	10,641,030
Operating Wavelength Range	nm	±5
Typ. Peak Isolation @23ºC@23°ºC	dB	30
Min.Isolation @23ºC	dB	26
Typical Insert loss@23ºC	dB	0.8
Max.Insertion Loss@23ºC	dB	1.0
Min. Extinction Ratio@23ºC(PM Fiber Type)	dB	20
Max. Polarization Dependent Loss@23ºC(Single Mode Fiber Type)	dB	0.15
Min. Return Loss(Input /Output )	dB	45
Max. Average Power	W	1 , 2, 5, 10 or Specified
Package Dimensions	mm	65x17x16
Max.ns pulse peak power	kW	10 or Specified
Max.Tensile Load	N	5
Operating temperature	ºC	+10~+50
Storage temperature	ºC	0~+60

Note: When utilizing connectors, handling power is restricted to 1W. Insertion loss will increase by 0.3dB, return loss will decrease by 5dB, and the extinction ratio will diminish by 2dB. The connector key is aligned with the slow axis.
Package Dimensions

Single

Dual

Detailed Photos Company ProfileShenzhen Kerns Tech Co., Ltd. is a Hi-Tech enterprise having its own brand and specializing in R&D, manufacture and sales of fiber optical communications equipment.The main products of Kerns Tech include optical combiner, isolator, circulator, optical devices, fiber optic patch cord, connector, adapter, optical coupler, attenuator, optic media converter, optic splice closure, optic terminal box, ODF etc, which are widely used in laser equipment, fiber optic equipment, laboratory research, instruments, telecommunications, broadband, broadcast, CATV and network industry.All the products acquired the approval of the Network Access License for Telecommunication Equipment Ministry of Information Industry, PRC, ISO9001, UL and CE standard, which ensure the reliability and make them sold very well not only in the domestic market but also the overseas market. Our AdvantagesAn optical fiber isolator is a passive device that allows light to travel in one direction through an optical fiber, while suppressing light traveling in the opposite direction. This is useful in many applications, such as laser systems, where back reflections can damage the light source or cause other issues. The level of suppression is called the optical isolation, and the higher the isolation, the better the source is protected.
