Knife Grinding Machine with High Quality (INNOVO-S)

Product Description

INNOVO-S knife grinder machine
Specifications
INNOVO-S knife grinder machine
manufactured by senior engineers
various of oblique knife edge
ideal equipment
low

INNOVO-S knife grinder machine
It is made according to years of knife grinder's precision manufacturing experience by Tianming printing machine and absorbs the advanced technology from Germany. It is a new type of grinding machine which sets sharpening, polishing in one. Its key electrical and key parts' bearing adopt the imported original documents, and it has reached the technological level of imports of similar knife grinders.

INNOVO-S knife grinder ma hine
Its gantry-type body adopts carbon constructional quality steel which has been heat treatment; its wheelhead transmission is rolling positioning linear guide. The water-cooled motor patented technology allows the co oling water spray from the wheel center so that the effect of cooling becomes better. The rotation speed of wheelhead and grinding wheel are controlled by the inverter, the speed of them are adjustable. Its wheelhead uses paste-type cylindrical grinding wheel to extend 1 / 3 service life of grinding wheel, so that greatly reduces the cost of milling knife; The polishing wheel head uses combined wool wheel polishing, can fully remove the knife chips.

INNOVO-S knife grinder machine is applicable to milling all kind s of lath-shaped straight blades (for example: the blades of linkage line knives, toilet paper scrapers, three-k nife trim mers, plastic pulverizers, paper cutting machines, wood chippers, plate shears ). It is an ideal grinding equipment for the printing, paper, wo od, pl astic leather, making panels and other industries, and it is the best choice for the grinding centers.

INNOVO-S knife grinder machine
Wheelhead System
01. Water-cooled motor (patent): cooling water emitted from the central wheel, center so that the effect of cooling become better
02. Wheelhead can move back and forth

Drive Mechanism
01. Sprocket chain drive

02. Transducer timing devices: travel speed and the wheelhead speed adjustable

Machine Structure
01. Gantry-type body: carbon constructional quality steel which has been heat treatment
02. Rolling positioning linear guide: Rail can be replaced, the life of machine is more longer, the maintenance costs of machine is more lower, the travel transmission of machine is more stable

Loading Knife Structure
01. Electric magnetic chuck: uniform suction, milling knife is more straight-line, effectively improved the work efficiency

Main Function Deployment
01. Centralized refueling devices: lubricating the main box, lift pallet, elevated screws
02. Grinding wheel automatic feed: automatic feed to grind knife
03. The polishing wheel head removes the knife chip devices: using combined wool wheel polishing, can fully remove the knife chip

Optional Device
01. Imports of electrical components: Schneider electric (optional, costs excluded)
02. Scraper Clamp: dedicated for toilet paper device (optional, costs excluded)


INNOVO-S knife grinder machine

No	Specifications / Model	Max grinding length	Overall dimensions	Machine net weight
	unit	mm	mm	kg
1	1600S	1700	4080x1000x1550	4200
2	2200S	2200	4680x1000x1550	4700
3	2600S	2600	5080x1000x1550	5200
4	2800S	2800	5280x1000x1550	5700
5	3000S	3000	5480x1000x1550	6200
6	3200S	3200	5680x1000x1550	6500
7	3500S	3500	5980x1000x1550	7000
8	4000S	4000	6580x1000x1550	7500
9	4500S	4500	7080x1000x1550	8000
10	5000S	5000	7580x1000x1550	8500

Item		Parameters
Machining maximum size (mm)	Length	Reference Maximum grinding length
	Width	200
	Thickness	60
knife shelf rotation range (degree)	0°-90°
grinding head back and forth speed(m/min)	5-15(Frequency conversion speed regulation)
Grinding speed	End face grinding head(right)	Frequency conversion speed regulation
	Polishing grinding head(left)	Frequency conversion speed regulation
Grinding head tilt Angle	End face grinding head(right)	0-5°
	Polishing grinding head(left)	3°
Grinding the maximum amount of vertical movement(mm)	End face grinding head(right)	150
	Polishing grinding head(left)	90
Feed range	Automatic vertical single trip	0-0.05
Dial each cell	0.02 mm
The handwheel every tooth	vertical feed	0.01mm/tooth
Size of working plat(mm)	length	1600-5000
	width	140-200
Grinding Wheel Size (mm)	End face grinding head grinding wheel	barrel-type Φ200×Φ150×100
	Polishing grinding head grinding wheel	Φ120×Φ18×12
Motor power(KW)	The grinding head motor	Flat grinding head made-to-measure
		Polishing grinding head Y90L-4 1.5
	Reciprocating motor	JW7124/WB100-WD-0.55
Motor power(KW)	cooling pump	WB100-WD-0.55
